MDF + Aluminum Material Conference Room Partitions / Folding Partition Walls Commercial
Product Details:
| Place of Origin: | China |
| Brand Name: | BUNGE |
| Certification: | ISO 9001 |
| Model Number: | 85 mm sliding partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | US Dollars $ 75 / 125 per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | 10-25 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Color: | Accept Customized | Thickness: | 85 Mm |
|---|---|---|---|
| Material: | MDF+Aluminum | Feature: | Sound Proofing |
| Product Name: | Sliding Partition Walls | Height: | 6 Meters |
| High Light: | acoustic sliding partition,sliding folding partition |
||
Product Description
Acoustic Conference Room Partition Hotel Sound Proof Sliding Partition Walls
Details about Sliding Partition Walls
Sliding partition walls can be applied in hotels, Muti-functions halls, Meeting Room, Convention Center, Residential area, College and School, Banquet hall, Training rooms etc. We provide quality and reliable services at very cost effective prices.
The sliding partition walls shall be top-supported, manually operated panels stacked in an area nominated in the plans. When closed, the operable wall shall provide a complete sound retardant barrier. No floor track shall be used. The tracks are made from extruded anodized aluminum. The sliding partition walls track housing shall utilize grooves and interlocking steel pins for better alignment of adjacent track section, and shall be reinforced overhead by drop rod brackets.
The sliding partition walls consist of a series of concave/convex profile interlocking flat panels and the fast set retractable top and bottom seals ,its provide excellent acoustic insulation property of from STC-32 to 53 in laboratory setting.
Its high performance per dollar value and the easiest in-field operation makes it very suitable for Hotel, banquet hall, conference room ,ballroom, muti-function hall, restaurant,classroom,office,religion,dance studio ,shopping arcades and many other place where seek for space divide with good soundproof performance .
Technical Information:
| Series | BG65 | BG80 / BG85 | BG100 & BG125 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
| Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
| Sound insulation | 32-38dB Rw | 36-45dB Rw | 42-55dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
FAQ of Sliding Partition Walls
1. Are you a trading company or a factory ?
Our company was established in Guangzhou city,with our own factory and showroom. We are a manufacturer engaged in sliding partition walls for more than 10 years. Welcome to pay a visit to our factory in Guangzhou.
2.How can you guarantee the quality?
We provide three years warrenty.
3.How to finalize orders?
Please send your room drawing and provide requirements like partition surface finished and soundproof requirements, we will design the sliding partition walls for free. After your confirmation, we can start production.
4.How long is the lead time.
Normally 10-25 days upon receiving the deposit, base on the quantity 300 SQM
5.Can you do the installation?
Yes, we can send engineer to guide installtion, details please contact us.
6.How is the soundproof quality ?
From 30dB to 55dB, depends of which type and what partition surface finished you need. Contact us and we will provide professional suggestions.
