Product Details:

Place of Origin: Guangdong
Brand Name: BANGE
Certification: ISO9001
Model Number: 85 mm sound proof partitions

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: US Dollars 80 - 120 per square meters
Packaging Details: Carton package, MDF batten on four section sides , foam board on both front face.
Delivery Time: 15-20 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Color: Accept Customized Application: Meeting Room,office
Material: MDF+Aluminum Type: Commercial Furniture
Feature: Sound Proofing Product Name: Sound Proof Partitions
High Light:

sounproof folding partition

,

movable soundproof partition

Product Description

Meeting Room Economical Sliding Folding Operable Soundproof Partition walls



Details of BUNGE Sound Proof Partitions



1.Sound proof partitions can separate the space speedy and conveniently.



2.Sound proof partitions top hung system without the need for a floor track.



3.Sound proof partition is made from high density aluminum frame, special made rubber, excellent sound insulation cotton and finish surface, etc.



4.Around the sound proof partition walls panel, there is sound insulation rubber, it can help to insulate the sound entering.



5.The sound proof partition walls panel is hanging on the aluminum track, assembled with muti direction wheels.

Economical Sliding Folding Operable Soundproof Partition Wall For Meeting Room 0
Specifications of Sound Proof Partitions System

Series BG65 BG80 / BG85 BG100 & BG125
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm / 85mm 100mm
Panel height Up to 4000mm Up to 6000mm Up to 18000mm
Max height 4000mm 6000mm 18000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame Aluminum frame Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire safety Optional Class I or O Optional Class I or O Optional Class I or O
Vertical profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles
Retractable seals Aluminum black with
double rubber seals
Aluminum black with double rubber seals Aluminum black with double rubber seals
Operation of seals Manual, with supplied
operating handle
Manual, with supplied operating handle Manual, with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass doors Single open in panel or
double open in two panel
Single open in panel or double open in two panel Single open in panel or double open in two panel
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx30-48kg/sq M
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

Economical Sliding Folding Operable Soundproof Partition Wall For Meeting Room 1

Features of Sliding Partition Walls



High specification ceiling track system.


Sound rating from Rw 30 to 50 dB.


Exposed protective edge or concealed profiles.


Individual plate is suspended from the top track.


Various stacking arrangements.


A telescopic seal locked between the track and the floor.


Access door is available for operable partitions.


The surface treatment may be used in hardwood veneer, vinyl, melamine, laminate or spray.

Economical Sliding Folding Operable Soundproof Partition Wall For Meeting Room 2
