Product Details:

Place of Origin: Guangdong
Brand Name: BANGE
Certification: ISO9001
Model Number: 85 mm sound proof partitions

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: US Dollars 80 - 120 per square meters
Packaging Details: Carton package, MDF batten on four section sides , foam board on both front face.
Delivery Time: 15-20 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Color: Accept Customized Application: Banquet Hall,hotel
Material: MDF+Aluminum Type: Commercial Furniture
Feature: Sound Proofing Product Name: Sound Proof Partitions
High Light:

movable sound proof partitions

,

movable soundproof partition

Product Description

85 mm Thickness Banquet Hall Acoustic Operable Sound Proof Partitions



Details of BUNGE Sound Proof Partitions



1) Sound proof partitions board is modernized decoration style. It can separate the space speedly and conveniently, it is ususally used in banqueet hall, school, hote etc.It has sound insulation and heat insulation and fireproof function.



2) Our sound proof partition is made of high quality anodized aluminum frame with composite materials.The panel Type 80 has astandard thickness of 65mm and a width up to1219mm. Maximum height can reach 4500mm tall.



3) Its vertical seal,together with the horizontal top and bottom retractable seals providing excellent acoustic insulation property of maximum STC-45.


4) The sound proof partitions may be finished with a selection from our standard un-finish MDF or un-finish plywood board, or with optional fabric, leather, melamine, high pressure laminate, murals, or other custom surfaces. And pass through door or glass window can be applied additionally.Property of maximum STC-45.




4) The sound proof partitions may be finished with a selection from our standard un-finish MDF or un-finish plywood board, or with optional fabric, leather, melamine, high pressure laminate, murals, or other custom surfaces. And pass through door or glass window can be applied additionally.

85 mm Thickness Banquet Hall Acoustic Operable Partition Walls Commercial Furniture 0
Specifications of Sound Proof Partitions System

Series BG65 BG80 / BG85 BG100 & BG125
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm / 85mm 100mm
Panel height Up to 4000mm Up to 6000mm Up to 18000mm
Max height 4000mm 6000mm 18000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame Aluminum frame Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire safety Optional Class I or O Optional Class I or O Optional Class I or O
Vertical profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles
Retractable seals Aluminum black with
double rubber seals
Aluminum black with double rubber seals Aluminum black with double rubber seals
Operation of seals Manual, with supplied
operating handle
Manual, with supplied operating handle Manual, with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass doors Single open in panel or
double open in two panel
Single open in panel or double open in two panel Single open in panel or double open in two panel
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx30-48kg/sq M
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

85 mm Thickness Banquet Hall Acoustic Operable Partition Walls Commercial Furniture 1

Features of Sliding Partition Walls



Many panel stack options are completely flexible;


No floor track to get in the way;


Individual acoustic partition wall panel can be stored to maximize the use of space.


Operable top and bottom seals for easy operation;


A wide range of surface finishes are available for sound proof partitions.


High performance multiple fill for maximum noise reduction;


Sound insulation aluminum frame structure, enhance the acoustic effect;


Unique track systems ensure quiet and easy operation;


Three panel thickness are available for a variety of acoustic requirements.

85 mm Thickness Banquet Hall Acoustic Operable Partition Walls Commercial Furniture 2
