Product Details:

Place of Origin: Guangdong
Brand Name: BANGE
Certification: ISO9001
Model Number: 85 mm movable partition walls

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: US Dollars 80 - 120 per square meters
Packaging Details: Carton package, MDF batten on four section sides , foam board on both front face.
Delivery Time: 15-20 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Movable Partition Walls Feature: Sound Insulation
Size: 85 Mm(3 1/4 Inch) Color: Accept Customized
Application: Banquet Hall,hotel,ballroom Material: MDF+Aluminum
High Light:

movable partitions systems

,

acoustic movable walls

Product Description

125 Ultra-High System Acoustic Operable Movable Partition Walls Malaysia

Specifications of Movable Partition Walls System

Model BG65 Series BG80 Series BG100 Series BG High-Series
Suspensionsystem Aluminum hanging Steal Hanging
Basic Thickness 65 mm 80 mm 100 mm 100 mm
Total thickness 65/75/85/95mm 80/90/100/110mm 100/120/130mm 100/120/130mm
Max Height Up to 3800 mm Up to 6000 mm Up to 8000 mm Up to 15000 mm
Width 600-1230mm 600-1230mm 800-1230mm 800-1230mm
Floor/Ceiling Sealing Strength Telescopic aluminum tube with rubber strip.
Side walls sealing strength Double seal tape
Sound insulation level 26-30 db 28-34 db 32-40 db 42-52 db
Panel structure Aluminum frame with wooden keel Aluminum frame with steel keel
Surface material Melamine laminate/fabric/PU leather/wallpaper/veneer/customized

125 Ultra - High System Acoustic Movable Operable Partition Walls Malaysia ISO9001 0
Advantages of Sliding Partition Walls



Individual panels that can be stored away for maximum space usage.


Operable top and bottom seals for effortless operation.


Aluminum frame construction for enhanced acoustics.


The system offers various levels of sound reduction.


Unique track and carrier system ensuring quiet and easy operation.


Numerous panel stacking options for complete flexibility.


Top hung and no floor track.

125 Ultra - High System Acoustic Movable Operable Partition Walls Malaysia ISO9001 1

Details of Sliding Partition Walls

Thickness: 100 mm
Width: 700-1200 mm
Height: 9000-17000 mm
Suspension: Top hang with single or double carrier
Acoustic performance: up to STC 55 dB



As the ultra high version, pattern 125 movable partition wall systems are made up of a series of individual partition panel with ceiling track which make it be able to slide along the track. These movable partition walls on wheels are widely used in hotels, shops, exhibition centers, exhibition center, colleges, clubs, art centers, stadium, sports centers, offices, testing center, bowling centers, schools, conference center, golf clubs, etc.



The nominal thickness of movable partition wall is 100 mm.


The movable partition walls panel frames are made of standard construction grade aluminum alloy.


Movable partition walls panels are available in 12mm thick MDF board, particle board, gypsum board.


Different soundproof material infill and surface material decide the acoustic performance to meet different STC requirements.

125 Ultra - High System Acoustic Movable Operable Partition Walls Malaysia ISO9001 2
