Multi Color Sound Proof Partitions , Commercial Operable Partition System For Function Hall
Product Details:
Place of Origin: | China,Guangzhou |
Brand Name: | BUNGE |
Certification: | ISO9001 |
Model Number: | Series 100 mm sound proof partition |
Payment & Shipping Terms:
Minimum Order Quantity: | 10 square meters |
---|---|
Price: | 108 / 137 dollar per square meter |
Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
Supply Ability: | 5000 square meters per month |
Detail Information |
|||
Service: | OEM Service | Structure: | Aluminium+MDF Board |
---|---|---|---|
Height: | 7 M | Color: | Multi Color |
Open Style: | Folding | Application: | Function Hall,hotel |
Thickness: | 100 Mm | Surface: | Melamine,acoustic Fabric |
High Light: | sounproof folding partition,movable soundproof partition |
Product Description
Soundproof Conference Room Sliding Folding Partition Wall
Description:
Our movable and operable partition system accessories are custom for each client and project,and they are also made of superior material.Track system for right-angled configurations with cross- roller carriers for element weights up to 500 kg. Support rollers in the junctions guarantee easy operation when sliding the elements across intersections .
Besides the high sound absorbing test,we have passed the Eco-protection test and Fireproof test,to ensure you to get the top quality product, and enjoy a safe , comfortable and low carbon emission way of life on movable and operable partition system.
Advantage:
1.Top hung with no floor track required.
2.Retractable acoustic seals at top and bottom of each panel operated either by a quick release handle.
3.Single or twin point suspension for central or offset stacking options.
4.Variable track arrangements.
5.Whiteboard or Painted.
6.Optional inset pass doors,easy to be in or out.
7.Closure panel fitted with face operated telescopic "nose".
Feature:
1. No need floor suspension: There is no track on the floor, just install the track on the ceiling;
2. Stable and safe: It is stable and reliable after being cut off, and it is not easy to swing;
3. Soundproof and environmental protection: sound insulation effect is good, the maximum sound insulation coefficient can reach 53 dB;
4. Insulation and energy conservation: excellent insulation performance, according to different seating rates, the large space is divided into small spaces to reduce the air conditioning power consumption;
Technical information:
TYPE | BG65 | BG85 | BG100 |
Panel suspension | Top hung only | ||
Track system | Single or twin point | ||
Panel thickness | 65 mm | 85 mm | 100 mm |
Panel height | Up to 4000mm,heights greater than 3000mm refer to our technical dept. | Up to 6000mm, heights greater than 6000mm refer to our technical dept. Inset passing doors above 2400mm. Full height passing door up to 3000mm high document ‘M’ disabled doors optional. | |
Max height | 4000mm | 6000mm | 18000mm |
Panel width |
500 - 1200mm 1' 5/8" -- 4' |
500 - 1200mm 1' 5/8" -- 4' |
500 - 1200mm 1' 5/8" -- 4' |
Frame | Aluminum | Aluminum | Aluminum |
Surface material | 9mm | 9mm | 12mm |
Fire safety | Optional class I | Optional class I | Optional class I |
Vertical profiles | Aluminum, anodized with sealing profiles, painter optional | Aluminum, anodized with sealing profiles, painter optional | Aluminum, anodized with sealing profiles, painter optional |
Retractable seals | Aluminum, black with double rubber seals | Aluminum, black with double rubber seals | Aluminum, black with double rubber seals |
Operation of seals | Manual, with supplied operating handle | ||
Locking | Optional lock to passing doors | ||
Passing doors | Single open in one panel or double open in two panel | ||
Sound insulation | 32-38dB Rw | 36-45dB Rw | 42-55dB Rw |
Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx 30-48kg/sq M |
Operation soundproof partition:
We usually use crank handle to operate panels to start sliding or solid. When the operable seals are retracted, panels glide effortlessly and quietly along the unique aluminium overhead track system (no need for floor guide).
Telescopic end panels enable the wall to be locked off to complete the acoustic seal. The track and carrier system provides ease of operation and directional flexibility, allowing panel stacking in countless configurations.
Structure:
The sliding partition wall panels are operated by means of an internal scissor-jack mechanism and move effortlessly along an aluminium head track, when closed they form a secure fixed wall.
Partition wall system is a high quality bespoke system to suit timber panels up to 150 kilogram in weight, there are multiple options for Door types, parking areas and track layouts.
Each door is a top hung straight sliding panel which sits inline with the other doors these panels can be moved into a parking area when the wall needs to be opened, pivot panels can be fixed or converted into sliding doors. Timber movable walls can be created to suit any space within reason.
