Floor to Ceiling Sliding Folding Room Partitions for Restaurant / Movable Divider Walls

Floor to Ceiling Sliding Folding Room Partitions for Restaurant / Movable Divider Walls

Product Details:

Place of Origin: China,Guangzhou
Brand Name: BUNGE
Certification: ISO9001
Model Number: Series 65 mm movable partition wall

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: 95 / 129 dollar per square meter
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face.
Delivery Time: Shipped in 10 days after payment, based on the quantity.
Payment Terms: D/A, D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability: 5000 square meters per month
Get Best Price Contact Now

Detail Information

Thickness: 65 Mm Height: 4 M
Width: 500-1200 Mm Open Style: Sliding
Position: Commercial Application: Restaurant,hotel
Surface: Leather
High Light:

movable walls on wheels

,

acoustic movable walls

Product Description

Floor to Ceiling Sliding Folding Room Partition Restaurant Movable Divider



Description:


Our movable partition system accessories are custom for each client and project,and they are also made of superior material.Track system for right-angled configurations with cross- roller carriers for element weights up to 500 kg. Support rollers in the junctions guarantee easy operation when sliding the elements across intersections .


Besides the high sound absorbing test,we have passed the Eco-protection test and Fireproof test,to ensure you to get the top quality product, and enjoy a safe , comfortable and low carbon emission way of life on movable and operable partition system.


Feature:


1.65mm ,85mm, 100mm aluminum frame thickness panel ,Max height up to 15 meters.


2.Top supported without floor track or guide, only have track on the ceiling.


3.clear anodized extruded aluminum tracks and frames,customized powder coated color are available.


4.Sound insulation certificate :STC 32db to 52db, ASTM standard of acoustic tested in Hong Kong.


5.Available in wide range of finishes, melamine ,fabric/PU leather, HPL, printing etc.


6.Fast delivery and Rich experiences in oversea project installation guide & supervision.



Floor to Ceiling Sliding Folding Room Partitions for Restaurant / Movable Divider Walls 0


Technical information:



Panel Suspension Top hanging system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum Or Steel Track
Roller on panel Single or Double Roller
Panel Frames Heavy-duty steel-gusseted aluminum inner frames reinforced with full height.
Top and bottom seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel Surface MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodized or polyester powder coating to all exposed aluminium components available in a wide range of colour as standard.



Introduction:



The movable partition wall is our individual panel partition system offering an acoustic insulation rating of up to 53 dB.


Ideally suited for high specification applications due to the sheer flexibility, numerous stacking arrangements available and the impressive acoustic qualities this system offers.



The panels are operated by means of an internal scissor-jack mechanism and move effortlessly along an aluminium head track, when closed they form a secure fixed wall.



Floor to Ceiling Sliding Folding Room Partitions for Restaurant / Movable Divider Walls 1



Application:



The movable wall series is used wherever room space needs to be fully utilized. Hotels, conference centers, educational establishments, offices, training areas, etc. can all benefit from the flexibility of Dividers operable walls.



Aluminium accessories details:



Track: The tracks are made from extruded 6063 - T5 anodized aluminium. The track housing shall utilize grooves and interlocking steel pins for positive alignment of adjacent track sections, and shall be reinforced overhead by drop rod brackets. Aluminum track housing shall include an integral nut slot to accept a hardened square nut for attaching each drop rod bracket to the top of the track.



Seals: vinyl seal of butane rubber will be used as top and bottom and as well as closure seals for the operable wall system.Retractable seal drop will be 23 mm.
