Sliding Aluminium Roller Track Acoustic Partition Wall For Muti - Function Hall
Product Details:
| Place of Origin: | Guangdong,China |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | 65 mm acoustic partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | 94 / 123 dollar per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, T/T, L/C, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Thickness: | 65 Mm | Material: | MDF Board+Aluminium |
|---|---|---|---|
| Height: | 4 M | Product Name: | Acoustic Partition Wall |
| Width: | 500-1200 Mm | Panel Style: | Melamine |
| High Light: | acoustic operable partitions,movable acoustic partition walls |
||
Product Description
Sliding Aluminium Roller Track Conference Room Acoustical Partition Wall
Description:
The acoustic partition walls are a new way to divide spaces with elegance, while respecting the architectural environment in which they are inserted.
They are composed of multiple individual elements, which flow along a horizontal guide attached to the ceiling, assembled one after another completing the entire wall.
It is not necessary any track on the floor, handling the elements is simple, fast and safe. The advantage of folding partition wall is essentially to occupy reduced space when it is parking, and when the wall is composed of all its elements.
Feature:
Individual panels that can be stored away for maximum space utilization.
Operable top and bottom seals for effortless operation.
Isolated aluminium frame construction for enhanced acoustics.
Acoustic partition wall has high performance multiple in fill's for maximum sound attenuation.
Unique track and carrier system ensuring quiet and easy operation.
Numerous panel stacking options for complete flexibility.
No floor track ensuring obstruction free threshold.
Application:
Its high performance per dollar value and the easiest in-field operation makes it very suitable for Hotel, banquet hall, conference room ,ballroom, muti-function hall, restaurant,classroom,office,religion,dance studio ,shopping arcades and many other place where seek for space divide with good soundproof performance .
Technical Information:
| Series | 65 | 85 | 100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 80 mm | 100 mm |
| Max height | 4000 mm | 6000 mm | 9000 mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9 mm | 9 mm | 9 mm |
| Pass doors | Single door or Double door | Single door or Double door | Single door or Double door |
| Sound insulation | 32-40dB Rw | 36-45dB Rw | 40-53dB Rw |
Operable acoustic partition wall:
We usuallly use crank handle to operate panels to start sliding or solid. When the operable seals are retracted, panels glide effortlessly and quietly along the unique aluminium overhead track system (no need for floor guide).
Telescopic end panels enable the wall to be locked off to complete the acoustic seal. The track and carrier system provides ease of operation and directional flexibility, allowing panel stacking in countless configurations.
Packing and shipping:
Packaging Details
Export carton box and wood pallet or customized packaging.
Delivery Time
Shipped in 18 days after receiving deposit payment, sliding partition wall quantity is less than 200 square meters.(T/T 40% deposit advanced,balanced before shipping).
Our service:
We design and manufacture value for many products with one year's warranty on all the outstanding ranges illustrated in this brochure.
They offer a complete service package covering site surveys, CAD technical drawings, and quotation presentation. Emphasis is placed on quality assurance backed by a comprehensive after sales service.
