Sound Insulation Folding Movable Partition Walls System For Banquet Hall

Sound Insulation Folding Movable Partition Walls System For Banquet Hall

Product Details:

Place of Origin: Guangdong
Brand Name: BANGE
Certification: ISO9001
Model Number: 85 mm movable partition walls

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: US Dollars 80 - 138 per square meters
Packaging Details: Carton package, MDF batten on four section sides , foam board on both front face.
Delivery Time: 15-20 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Colors: Can Be Customized Height: 2000/13000 Mm
Application: Banquet Hall,hotel Product Name: Movable Partition Walls
Feature: Sound Proof Type: Commercial Furniture
High Light:

movable walls on wheels

,

acoustic movable walls

Product Description

Banquet Hall Sound Proof Folding Movable Partition Walls System



Specifications of BUNGE Movable Walls System



Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Panel thickness 65mm 85mm 100mm
Max height 4000mm 6000mm 18000mm
Panel width 500-1200 mm 500-1200 mm 500-1200 mm
Face material 9mm 9mm 12 mm
Pass doors Single door or Double door
Sound insulation 28-38dB Rw 28-42dB Rw 32-50dB Rw
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

Sound Insulation Folding Movable Partition Walls System For Banquet Hall 0

Features of BUNGE Movable Walls System

1- 65mm ,85mm, 100mm aluminum frame thickness panel ,Max height up to 15 meters.



2-Top supported without floor track or guide, only have track on the ceiling.



3- Clear anodized extruded aluminum tracks and frames,customized powder coated color are available.



4- Sound insulation certificate :STC 32db to 52db, ASTM standard of acoustic tested in HongKong.



5- Available in wide range of finishes, melamine ,fabric/PU leather, HPL, printing etc.



6- Fast delivery and Rich experiences in oversea project installation guide & supervision.

Sound Insulation Folding Movable Partition Walls System For Banquet Hall 1

Procedure of Installing Movable Walls System



1. Please designate the responsible person before construction and leave contact information to facilitate communication between the two parties on construction logistics.



2. If the ground has been finished before the track construction, if the carpet, floor tiles, floor, etc. have been laid, you need to do ground protection to prevent the welding sparks from damaging the ground.



3. You need to provide the height of the shed after the decoration is completed. We will determine the height of the track installation according to this height.



4. Because we need to calculate the size of the hanging track, you need to provide the net size of the finished wall and the pillar. We will hang the track according to this size.



5. After the movable walls track suspension is completed, the reserved wall size given by you cannot be changed. Because we calculate the construction according to this size, if the size is changed, the door panel will not operate.



6. The movable walls partition should be horizontally perpendicular to the ground directly below the track, and the error should not exceed 1cm.



7. If there are other constructions at the same time, please do not pierce the foreign objects such as nails and insert them on the installed rails. This will cause the door pulleys to not run in the track.



8. Each group of tracks will have a “raw mouth”, which will be removed before installing the door panel, and then installed after the door panel is installed. This "raw mouth" cannot be sealed.



9. In order to facilitate future maintenance, please reserve the inspection port near the ceiling track to facilitate the maintenance personnel to enter the inspection port for product maintenance.



10. After the movable walls panels are hung, it needs to be debugged. Please remember do not use the movable walls panel before our personnel have debugged the panel, otherwise forcible use will result in damage to the movable wall panels.





Common Applications of Movable Walls System



BUNGE soundproof movable walls can be used in Convention Centers,Gymnasiums,Religious Facilities,Hotels,Auditoriums,Corporate Training Facilities,Office,Civic or Exposition Halls,Schools, Banquet Halls,Meeting Rooms etc.



With movable walls systems,there are no more barriers to maximizing the potential of your available building spaces.

Sound Insulation Folding Movable Partition Walls System For Banquet Hall 2
