|Thickness:||65 Mm||Height:||4 M|
|Width:||500-1200 Mm||Open Style:||Sliding|
Removable wall partition is our top of the range operable walls. The system offers several layouts and stacking arrangements to create many useful areas within the working space.
Removable wall partitions are solid acoustic sliding partitions available in three varying thicknesses and laboratory tested sound rating up to Rw 53dB. This system is top hung. Each panel is individually supported by a track system mounted on the ceiling. No floor track is required.
To create the seal, each panel has interlocking vertical profiles and retractable rubber seals.
Maximize Your Space.
Moveable walls provide a simple and cost-effective way of generating space. We have installed them in a wide range of commercial and public sector environments including offices, exhibition halls, and conference areas.
Quick to install and easy to operate, moveable walls are popular and functional. They maximize space and versatility in the workplace and provide powerful acoustic and fire performance, whilst seamlessly blending into your interior design thanks to a huge variety of possible finishes.
|Panel Suspension||Top hanging system without the need for a floor track.|
|Panel Width||Each panel 600mm-1200mm.|
|Track||Aluminum Or Steel Track|
|Roller on panel||Single or Double Roller|
|Panel Frames||Heavy-duty steel-gusseted aluminum inner frames reinforced with full height.|
|Top and bottom seals||Top and bottom pressure retractable seals ensure effortless moved and locked.|
|Module||700mm - 1200mm maximum.|
|Panel stacking||Numerous panel stacking options for complete flexibility.|
|Panel Surface||MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.|
|Finishes||Satin anodized or polyester powder coating to all exposed aluminium components available in a wide range of colour as standard.|
Type 65 is suitable to use at 2m-3.5m height space.
Type 85 is suitable to use at 2m-6m height space.
Type 100 is suitable to use at 3m-9m height space
Each panel load-bearing weight: 225kgs/ 450kgs/ 650kgs
Sound insulation coefficient:
Type 65 highest sound insulation coefficient can be reach is 36db.
Type 85 the highest sound insulation coefficient can be reach is 50db.
Type 100 the highest sound insulation coefficient can be reach is 53db.
Parking removable wall partition:
1. If there is a door in the door, first turn the square hole on both sides of the door to rotate 180 degrees, loosen the upper and lower seals through the transmission wheel, and then close the door in the door;
2, Open the last screen of the telescopic aluminum plate and the upper and lower seals;
3. Retract the telescopic aluminum plate of the last screen so that its distance can at least turn the distance of the screen, generally about 140mm; 4. Push the screen to the position of the screen in the direction of the track.
4. After each group of screens is collected in the same way, press each two screens tightly to minimize the distance between the screens and the screens. If necessary, you can open the up and down motion seals of the last screen that is housed at the hidden plate so that it presses against the rails and the ground. This will prevent others from easily pulling the screen out.
