Interior Design Collapsible Movable Partition Walls / Sliding Folding Partitions Movable Walls
Product Details:
| Place of Origin: | Guangdong |
| Brand Name: | BANGE |
| Certification: | ISO9001 |
| Model Number: | 85 mm movable partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | US Dollars 80 - 138 per square meters |
| Packaging Details: | Carton package, MDF batten on four section sides , foam board on both front face. |
| Delivery Time: | 15-20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Width: | 85 Mm(3 1/4 Inch) | Open Style: | Sliding |
|---|---|---|---|
| Application: | Hotel,banquet Hall | Panel Width: | 500 Mm--1230 Mm |
| Product Name: | Movable Partition Walls | Position: | Interior |
| Colors: | Accept Customized | Surface: | Melamine |
| Feature: | Sound Proofing | ||
| High Light: | movable walls on wheels,movable partitions systems |
||
Product Description
Interior Design Collapsible Acoustic Sliding Folding Movable Partition Walls
Technical Specification
Panel Configuration – The movable partition wall panels are customized to meet specific requirements. Each movable partition walls board thickness is 100mm and max width is 1200mm. Each single movable partition wall panel is welded with a welded aluminum frame and 9mm MDF is mounted on both sides of the outer surface. The internal structure is made of steel mechanism, which combines excellent performance at the top and bottom of the telescopic sound seal. Internal space is filled with less than 64 kg/m3 glass wool.
Overhead track system – specific aluminum alloy rails to meet the necessary stacking requirements. The intersection design should prevent the track wheel from falling into the track groove. Heavy-duty multi-way roller enables easy movement of the sliding movable partition walls for rooms through the ceiling track.
The movable room partition walls has a unique fast seal winding mechanism and a solid vertical seal edge profile to ensure that all panels fit perfectly.
Sound Seal System – Built-in excellent retractable top and bottom seals are anodized by extruded aluminum channels, rubber sealed, and operated by a handle with a cap lock system with spring-loaded telescopic rods. The vertical seal of each panel is made of thick and tongue-type extruded aluminum laminated with rubber seal.
Top and bottom seals do not collected to the ceiling track and floor during panel’s movement. When the sound seals are combined, the movable partition walls panel is placed in a stable position, and the top and bottom seals are compressed on the rails and floors by tight acoustic seals, including adjustable telescopic panels.
Acoustic Rating – Movbale partition walls with high acoustic performance should provide an average sound attenuation of 45Db to 50DB.
Weight – The weight of each movable partition walls panel should be an average of 40 kg/m2, depending on the panel size.
Panel surface – By default it’s 9mm MDF board. However, it can be adapted to any decorative design, such as wood veneer, fabric, etc.
Applications and operations – The movable partition walls consist of a series of single flat wall panels that are manually operated and allow stacking flexibility of the center or remote side.
Specifications of Acoustic Movable Partition Walls System
| MODEL | 65 movable partition wall | 80 movable partition wall |
| Panel Thickness | 65mm | 85mm |
| Panel Width | 680mm-1210mm | 680mm-1230mm |
| Panel Hight | 2000mm-4500mm | 3000mm-6500mm |
| Frame | GB 6063 T6 Aluminium | GB 6063 T6 Aluminium |
|
Acoustic alreduction coefficient(db) |
32db | 45db |
|
Hermetic flex distance(mm) |
45mm | 45mm |
| Weight(kg/m) | 17,19,20,24 | 24,25,28,38 |
| Panel Material |
Class-fibr board,Melamine decorative lamminate board, Gypsum board,Color steel plate ,Fiberboard,Tempered glass |
Class-fibr board,Melamine decorative lamminate board, Gypsum board,Color steel plate,Fiberboard,Tempered glass |
| Panel Surface Finish |
Anodizing,electrophoresis, Powder coating; Wooden grain or customize surface treatment |
Anodizing,electrophoresis, Powder coating; Wooden grain or customize surface treatment |
| Advantages |
65 light-based activities are cut off cut off,their light weight,flexible operation,each door can be a single A hanging round hanging sliding door can be rotated 360 degrees,or two hanging round hanging round slide can turn. |
85 screen-based activities are better off cost, weight,moderate and flexible operation,each door can be a single hanging round hanging sliding door can be rotated 360 degrees,or two hanging round hanging round slide can be Tum can be pushed to move anywhere. Slide show steady and smooth transformation of space diversity. |
| High degree | 2-4.5m | 3-6.5m |
|
The largest rail loading |
250kg/m | 450kg/m |
| Usage |
Widely used in hotels,guesthouses and medium-sized exhibition, multi-functional conference hall. |
Widely used in hotels,luxury suites, function rooms,exhibition center. |
| Installation methods |
slide type, curve type and folding type. |
slide type, curve type and folding type. |
| MODEL | 100 movable partition wall | Ultrahigh movable partition wall |
| Panel Thickness | 100mm | 120mm |
| Panel Width | 680mm-1230mm | 680mm-1230mm |
| Panel Hight | 5000mm-8500mm | 7000mm-17000mm |
| Frame | GB 6063 T6 Aluminium | GB 6063 T6 Aluminium |
|
Acoustic alreduction coefficient(db) |
60db | 60db |
|
Hermetic flex distance(mm) |
45mm | 60mm |
| Weight(kg/m) | 40,45,48,55 | 60,60,60,60 |
| Panel Material |
Class-fibr board,Melamine decorative lamminate board ,Gypsum board,Color steel plate,Fiberboard,Tempered glass |
Class-fibr board,Melamine decorative lamminate board, Gypsum board,Color steel plate ,Fiberboard,Tempered glass |
|
Panel Surface Finish |
Anodizing,electrophoresis, Powder coating; Wooden grain or customize surface treatment |
Anodizing,electrophoresis, Powder coating; Wooden grain or customize surface treatment |
| Advantages |
100 active partition is partition noise effect of a good,moderated 360 degrees,or both may be round hanging Tum can push the slide to any place.Slide show steady and smooth transformation of space diversiyt. |
Ultra-high partition screens employ heavy-duty steel rails and steel hanging wheels that the effective sliding can amount to 100,000 times,which is a leading technology in partition industry. |
| High degree | 5-8.5m | 7-17m |
|
The largest rail loading |
650kg/m | 1250kg/m |
| Usage |
Widely used in various types of training room,a large hotel,banquet hall. |
Widely used in airports and large exhibition hall and place. |
| Installation methods | slide type, curve type and folding type. | slide type and folding type. |
The features of movable partition walls
Extensive worldwide sales network that has proved that our movable partition walls work well worldwide.
Technical advice or design is available, no matter where your facility is.
Integrated space management and acoustic product solutions that can be more profitable and economical to use in your building environment.
From your first query to the completion of the project, we are here to support.
Based on years of experience in architectural and design challenges, provide industry-leading technology to solve your space problems.
Unique custom applications that is flexible enough to meet the needs of any customer.
Strong industry support for other acoustic problems, not just movable partition walls, but also acoustic wall and ceiling.
For more information about our movable partition walls, please contact us for more details.
