Banquet Hall Acoustic Movable Wooden Room Partition / Sliding Sound Proof Partition Wall
Product Details:
| Place of Origin: | Guangdong |
| Brand Name: | BANGE |
| Certification: | ISO9001 |
| Model Number: | 85 mm sliding partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | US Dollars 80 - 138 per square meters |
| Packaging Details: | Carton package, MDF batten on four section sides , foam board on both front face. |
| Delivery Time: | 15-20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Width: | 85 Mm(3 1/4 Inch) | Open Style: | Sliding |
|---|---|---|---|
| Feature: | Sound Proofing | Application: | Hotel,banquet Hall |
| Panel Width: | 500 Mm--1230 Mm | Product Name: | Sliding Partition Walls |
| Position: | Interior | Colors: | Accept Customized |
| Surface: | Melamine | ||
| High Light: | acoustic sliding partition,sound proof sliding partitions |
||
Product Description
Banquet Hall Acoustic Movable Wooden Room Partitions Soundproof Sliding Partition Walls
The details of sliding partition walls
Model: BG65,BG85,BG100 Sliding Partition Wall
Sliding Partition wall thickness: 65mm~2.56inch, 85mm~3.35inch, 100mm~3.9inch
Board thickness: 9mm or 12mm
Blinds thickness: 16mm,25mm
Sliding Partition-wall standard length: ANY
Sliding Partition-wall standard height: 2000—13000mm, 78.7inch ~ 512inch
Optional material: Fabric/Melamine board/Glass/metal board/Aluminum Composite Panel/Soft panel/Blinds/Wooden board
Description sliding partition wall / folding door / movable wall /
Characteristic: Movable / Stable Structure/ Sound insulation / Pro-environment/ fireproofing / Stylish
Product dominant: Design systematization / Industrialization productions / Standardization Installation / Diversification working / Modernization appearance
Service: Supply consulting service, CAD project, office layout design /Work environment consulting /Products instruction
Sales Countries: Mace in china. Sales all over the world.
Specifications of Acoustic Sliding Partition Walls System
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65mm | 85mm | 100mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9mm | 9mm | 12 mm |
| Pass doors | Single door or Double door | ||
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
The 65 mm frame of the sliding partition walls
The frame of the 65-type sliding partition walls refers to the material used for the frame when the door panel is spliced. The 6055-T6 high-hardness aluminum alloy material can be used as the raw material for the partitioning aluminum alloy. The conventional oxidation color can be processed according to the customer's other colors.
The total thickness of the 65-type sliding partition walls frame can be 65mm. According to the thickness of the door panel, there are several models such as 65 type, 85 type and 100 type.
The 6-type mobile sliding partition walls uses 9mm slots on both sides as the fixed position of the board, and the middle is filled with soundproof cotton. Built-in transmission rod, with the principle of jack, easy to lock the sliding partition wall with the transmission setting, the fixed partition wall is as strong and solid as the solid wall. As long as the track is pre-buried before the ceiling is made, there is no need to lay the track on the ground.
