Product Details:

Place of Origin: China,Guangzhou
Brand Name: BUNGE
Certification: ISO9001
Model Number: Series 85 mm sliding partition wall

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: 89 /117 dollar per square meter
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face.
Delivery Time: Shipped in 10 days after payment, based on the quantity.
Payment Terms: D/A, D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability: 5000 square meters per month
Get Best Price Contact Now

Detail Information

Application: Classroom,office Height: 6 M
Material: MDF Board+Aluminium Thickness: 85 Mm
Color: Multi Color Open Style: Folding
Position: Commercial Width: 500-1200 Mm
Service: OEM Service
High Light:

acoustic sliding partition

,

sliding folding partition

Product Description

Movable Aluminium Door Track Acoustic Folding Room Divider Sliding Partition Wall

Description:



Sliding wall system is a high quality bespoke movable wall system to suit timber panels up to 150 kilogram in weight, there are multiple options for Door types, parking areas and track layouts.



Each door is a top hung straight sliding panel which sits inline with the other doors these panels can be moved into a parking area when the wall needs to be opened, pivot panels can be fixed or converted into sliding doors. Timber movable walls can be created to suit any space within reason.



Technical information:



Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Panel thickness 65 mm 85 mm 100 mm
Max height 4000 mm 6000 mm 18000 mm
Panel width 500-1200 mm 500-1200 mm 500-1200 mm
Face material 9 mm 9 mm 12 mm
Pass doors Single door or Double door
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw



Finish Material

Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)



Movable Aluminium Door Track Acoustic Folding Room Dividers / Sliding Partition Wall 0



Advantage:



1.Sound proof board is modernized decoration style. It can separate the space speedy and conveniently. And it has sound insulation and heat insulation and fireproof function.


2.The room dividers is made from high density s/s frame, special made rubber, excellent sound insulation cotton and finish board etc. the finish board is flat and hard.


3.The finish board is inserted in the aluminum track, assembled with muti direction wheels; the board can be stored in may different ways.



Feature:



1. No need floor suspension: There is no track on the floor, just install the track on the ceiling;


2. Stable and safe: It is stable and reliable after being cut off, and it is not easy to swing;


3. Soundproof and environmental protection: sound insulation effect is good, the maximum sound insulation coefficient can reach 53 dB;


4. Insulation and energy conservation: excellent insulation performance, according to different seating rates, the large space is divided into small spaces to reduce the air conditioning power consumption;


5.High-efficiency fire prevention: The use of high-efficiency fireproof materials, good fireproof performance.



Movable Aluminium Door Track Acoustic Folding Room Dividers / Sliding Partition Wall 1



Operation sliding partition:



All operations should be gentle and should pay attention to safety. Facing the screen station, use both hands to grab the screen and pull the screen in the direction of the rails; turn the screen in the direction of the rails.



After pushing the screen to its place, fix the screen. Tip: When pushing the screen to the intersection, you should pay attention to the direction of the rail, and then gently push the screen along the rail to the position where it should be placed.



Application:



At present, the sliding partition wall and fixed partition wall products have been widely used in hotels, guesthouses, mufti-function halls, conference rooms, banquet halls, office buildings, exhibition halls, financial institutions, government office buildings, hospitals, factories and other occasions. Basic functions: Active partition refers to the facade that separates the interior space.
