Banquet Hall Movable Partition Walls / Ballroom Folding Sliding Partition
Product Details:
Place of Origin: | Guangdong |
Brand Name: | BANGE |
Certification: | ISO9001 |
Model Number: | 85 mm movable partition walls |
Payment & Shipping Terms:
Minimum Order Quantity: | 10 square meters |
---|---|
Price: | US Dollars 80 - 120 per square meters |
Packaging Details: | Carton package, MDF batten on four section sides , foam board on both front face. |
Delivery Time: | 15-20 days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 50000 square meters per month |
Detail Information |
|||
Open Style: | Sliding | Product Name: | Movable Partition Walls |
---|---|---|---|
Feature: | Sound Proofing | Size: | 85 Mm |
Color: | Accept Customized | Application: | Office,hotel,conference Room |
Panel Width: | 500 Mm--1230 Mm | Door Material: | Melamine Board |
Surface: | Melamine,leather,fabric,plywood | Position: | Interior |
Width: | 85 Mm(3 1/4 Inch) | ||
High Light: | movable walls on wheels,acoustic movable walls |
Product Description
Ballroom Folding Sliding Partitions Banquet Hall Movable Partition Walls
Details of Movable Partition Walls System
BUNGE movable partition walls are made from mobile glass panels and are the ideal solution for teaching center and conference rooms and the division of waiting areas in airports and stations, entrance areas in banks, post offices and so on. The top and bottom locking and supporting edges of the door panels close along the whole width.
The structure is such that the glass need not be broken, rendering its life longer, and eventual repair work minimal. The covers for the top and bottom locking and supporting edges can be fixed using a clip. In this way surfaces are protected from both damage and scratching during assembly.
The sliding track is grooved, and with the correct screws it becomes possible to attach angle irons, for example for a false ceiling, without damaging the sliding track. The various surface finishes and wide range of colors ensure that the creativity employed will complement the architecture of the office perfectly.
The cover sheets are inter-changeable, allowing a new color scheme to be introduced at any moment. High-precision ball bearings guarantee a smooth slide and minimum sound, at a maximum weight of 150kg of the leaf. The various positioning possibilities of the panels (parallel/at 90° to the sliding track, or other) ensure that a solution is found to every requirement. The sliding track may be straight, curved or have a polygonal shape.
Specifications of Movable Partition Walls System
Series | BG65 | BG85 | BG100 |
Panel suspension | Top hung only | Top hung only | Top hung only |
Panel thickness | 65mm | 85mm | 100mm |
Max height | 4000mm | 6000mm | 18000mm |
Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
Face material | 9mm | 9mm | 12 mm |
Pass doors | Single door or Double door | ||
Sound insulation | 28-38dB Rw | 28-42dB Rw | 32-50dB Rw |
Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) |
65 mm frame of the Movable Partition Walls System
The frame of the 65-type movable partition refers to the material used for the frame when the door panel is spliced. The 6055-T6 high-hardness aluminum alloy material can be used as the raw material for the partitioning aluminum alloy. The conventional oxidation color can be processed according to the customer's other colors.
The total thickness of the 65-type partition frame can be 65mm. According to the thickness of the door panel, there are several models such as 65 type, 85 type and 100 type.
The 6-type mobile partition uses 9mm slots on both sides as the fixed position of the board, and the middle is filled with soundproof cotton. Built-in transmission rod, with the principle of jack, easy to lock the partition wall with the transmission setting, the fixed partition wall is as strong and solid as the solid wall. As long as the track is pre-buried before the ceiling is made, there is no need to lay the track on the ground.
