Product Details:

Place of Origin: Guangdong
Brand Name: BANGE
Certification: ISO9001
Model Number: 85 mm sliding partition walls

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: US Dollars 80 - 120 per square meters
Packaging Details: Carton package, MDF batten on four section sides , foam board on both front face.
Delivery Time: 15-20 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Open Style: Sliding Product Name: Sliding Partition Walls
Feature: Sound Proofing Size: 85 Mm
Color: Accept Customized Application: Office,hotel,conference Room
Panel Width: 500 Mm--1230 Mm Door Material: Melamine Board
Surface: Melamine,leather,fabric,plywood Position: Interior
Width: 85 Mm(3 1/4 Inch)
High Light:

acoustic sliding partition

,

sound proof sliding partitions

Product Description

High Aluminum Frame Sliding Office Movable Sliding Partition Walls



Advantages of Sliding Partition Walls



  • Design and Technology

Design and technology are the essentials of a successful alliance of sliding partition walls. The transformation of a large hall into two or more sound-insulated areas which perfectly respond to the requirements of the designer and the needs of the final user without sacrificing style and functionality, can all be achieved by means of Bunge movable sound-insulated walls. In view of the wide choice of finish available, Bunge movable sliding partition walls can be personalized according to the individual whim or requirement.

  • Widely application

The operable sliding partition wall series is used wherever room space needs to be fully utilized. Hotels, conference centers, multi-function rooms, banquet halls, offices, training areas, etc. can all benefit from the flexibility of Bunge movable operable walls.

Movable Sliding Partition Walls High Aluminum Frame Interior Position 0



Specifications of Sliding Partition Walls System



Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Panel thickness 65mm 85mm 100mm
Max height 4000mm 6000mm 18000mm
Panel width 500-1200 mm 500-1200 mm 500-1200 mm
Face material 9mm 9mm 12 mm
Pass doors Single door or Double door
Sound insulation 28-38dB Rw 28-42dB Rw 32-50dB Rw
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

Movable Sliding Partition Walls High Aluminum Frame Interior Position 1



Procedure of installing the sliding partition walls



1. Please designate the responsible person before construction and leave contact information to facilitate communication between the two parties on construction logistics.



2. If the ground has been finished before the track construction, if the carpet, floor tiles, floor, etc. have been laid, you need to do ground protection to prevent the welding sparks from damaging the ground.



3. You need to provide the height of the shed after the decoration is completed. We will determine the height of the track installation according to this height.



4. Because we need to calculate the size of the hanging track, you need to provide the net size of the finished wall and the pillar. We will hang the track according to this size.



5. After the track suspension is completed, the reserved wall size given by you cannot be changed. Because we calculate the construction according to this size, if the size is changed, the door panel will not operate.



6. After the track suspension is completed, our construction personnel will fill in the dimensional confirmation letter to provide accurate data for the production of the wallboard. You need to specify the person in charge of the site to confirm.



7. The sliding parrtition walls should be horizontally perpendicular to the ground directly below the track, and the error should not exceed 1cm.



8. If there are other constructions at the same time, please do not pierce the foreign objects such as nails and insert them on the installed rails. This will cause the door pulleys to not run in the track.



9. Each group of tracks will have a “raw mouth”, which will be removed before installing the door panel, and then installed after the door panel is installed. This "raw mouth" cannot be sealed.



10. In order to facilitate future maintenance and maintenance, please reserve the inspection port near the ceiling track to facilitate the maintenance personnel to enter the inspection port for product maintenance and maintenance.



11. If you need to improve the sound insulation effect of the product, after the track is hung, you can make sound insulation between the track and the original shed.



12. After the sliding partition walls panel are hung, it needs to be debugged. Active partition reminder Do not use the door panel before our personnel have debugged the door panel, otherwise forcible use will result in damage to the door panel.

Movable Sliding Partition Walls High Aluminum Frame Interior Position 2
