Aluminium Track Floor to Ceiling Sliding Partition Wall / Acoustic Room Dividers
Product Details:
| Place of Origin: | China,Guangzhou |
| Brand Name: | BUNGE |
| Certification: | ISO9001 |
| Model Number: | Series 65 mm sliding partition wall |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | 94 /123 dollar per square meter |
| Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
| Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 square meters per month |
|
Detail Information |
|||
| Application: | Office,conference Room | Height: | 4 M |
|---|---|---|---|
| Material: | MDF Board+Aluminium | Thickness: | 65 Mm |
| Color: | Multi Color | Open Style: | Folding |
| Position: | Commercial | Width: | 500-1200 Mm |
| Service: | OEM Service | ||
| High Light: | acoustic sliding partition,sound proof sliding partitions |
||
Product Description
Aluminium Track Acoustic Room Dividers Floor to Ceiling Sliding Partition Wall
Description:
The movable partition brings great convenience to people's work. For example, if you want to move the screen, you can fold it aside when you need it, so that the two spaces can be temporarily joined together to make them appear bigger.
This facilitates temporary departmental meetings. Some of these products use non-ground rail systems and have the ability to fully achieve the same solid wall effect.
Technical information:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Max height | 4000 mm | 6000 mm | 18000 mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9 mm | 9 mm | 12 mm |
| Pass doors | Single door or Double door | ||
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
|
Finish Material |
Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Structure:
Movable partition wall is composed of many single panels.Each panel is equipped with single or two hanging rollers.It depends on the horizontal hanging roller to make the partition panel hanging along the track.The vertical contact points of each single panel are connected by concave and convex positions.The seal rubbers are embedded and panel top and bottom parts are equipped with a retractable mechanism.
Feature:
1.There is no track on the floor, just install the track on the ceiling;
2.Using environmental material, the maximum sound insulation coefficient up to 53 db;
3.During production,our factory usually use high-efficiency fireproof materials, it can make panels have good fireproof performance;
4.According to different customers requests ,we can design different surface decoration.Usually we suggest customers surface that it can be combined with the indoor decoration effect to choose.
5.The partitions can move really flexibility, only one person can complete the entire process of partitioning;
6.When closing, the partition can be hidden in a dedicated storage cabinet, which does not affect the overall appearance.
Track system:
For single or paired panels up to 250kg. One 4-wheeled carrier is provided per panel, each wheel is consists of molded polymer tires on hardened steel ball bearings.Resilient mounted body for quite operation and load distribution.special for center stacking option. Usual dimension from the ceiling to the structure is 200mm.
For Omni-directional panel up to 225kg. Two carriers are provided per panel. Each carrier has two horizontal counter-rotating wheels that roll (not slide) in the track. Each wheel has precision ground bearings, encased with POM for quiet operation. Carriers easily negotiate square or angled corners without switches. Usual dimension from the ceiling to the structure is 200 mm.
Our service:
Supply you excellent design proposal.
Supply you prompt and competitive price.
Supply you strict quality-compliance and punctual delivery.
Organize the shipment for you.
Reliable after service: timely service and efficient response.
