Commercial Temporary Office Acoustic Room Dividers Melamine Surface 4m Height

Good quality Movable Partition Walls for sales
Good quality Movable Partition Walls for sales
We had installed the partition wall - it worked out well and our customer is happy. So we would like to thank you for delivering high quality goods an

—— Frank

I am so glad to cooperate with Bunge. Their products with good quality and pretty competitive price. My customers like it very much.

—— Grace

We have a lot of business with Bunge since 2011 ,I hope we have more orders and they continue to give our best service and quality.

—— Roger

Bunge is very serious and responsible supplier , partition walls have good quality and high sound proof .

—— Charles

I'm Online Chat Now

Commercial Temporary Office Acoustic Room Dividers Melamine Surface 4m Height

China Commercial Temporary Office Acoustic Room Dividers Melamine Surface 4m Height supplier
Commercial Temporary Office Acoustic Room Dividers Melamine Surface 4m Height supplier Commercial Temporary Office Acoustic Room Dividers Melamine Surface 4m Height supplier Commercial Temporary Office Acoustic Room Dividers Melamine Surface 4m Height supplier Commercial Temporary Office Acoustic Room Dividers Melamine Surface 4m Height supplier

Large Image :  Commercial Temporary Office Acoustic Room Dividers Melamine Surface 4m Height

Product Details:

Place of Origin: China,Guangzhou
Brand Name: BUNGE
Certification: ISO9001
Model Number: Series 65 mm acoustic room divider

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: 87/139 dollar per square meter
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face.
Delivery Time: Shipped in 10 days after payment, based on the quantity.
Payment Terms: D/A, D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability: 5000 square meters per month
Contact Now
Detailed Product Description
Finished: Melamine,leather,fabric Height: 4 M
Certificate: ISO9001 Width: 500-1200 Mm
Position: Commercial Sliding Door Type: Folding Doors
Product Name: Acoustic Room Divider Thickness: 65 Mm
Application: Classroom,office

Office Partition Walls,Sliding Folding Acoustic Room Divider,Commercial Room Partition



Specification:



The acoustic room divider is an individual panel partition wall system, designed to maximize noise reduction whilst manipulating interior space. 53 dB noise reduction is achieved with a combination of operable top and bottom seals, high performance multiple and a panel assembly design that allows an acoustic break between the frame and outer layer. The panels can be supplied with almost any surface finish, including MDF board bare finish, acoustic fabric and leather, melamine.



Acoustic Room Divider Feature:



Individually operated, top hung panels, purpose made to suit any opening size upto 10 metres high.


Retractable top and bottom seals, able to deal with floor level differences up to 22.5 mm.


Mechanically operated by worm screw drive providing 2 Kn of pressure for optimal acoustic performance.


No floor track.


Curved layouts, corner panels, junction panels, glazing cutouts, matching recess doors to special order.


Suitable for internal use only with a wide variety of features and finishes.



Commercial Temporary Office Acoustic Room Dividers Melamine Surface 4m Height



Technical information:



Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Panel thickness 65 mm 85 mm 100 mm
Max height 4000 mm 6000 mm 18000 mm
Panel width 500-1200 mm 500-1200 mm 500-1200 mm
Face material 9 mm 9 mm 12 mm
Pass doors Single door or Double door
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw



Finish Material

Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)



Introduction:



The acoustic room divider is our individual panel partition system offering an acoustic insulation rating of up to 53 dB.


Ideally suited for high specification applications due to the sheer flexibility, numerous stacking arrangements available and the impressive acoustic qualities this system offers.



The panels are operated by means of an internal scissor-jack mechanism and move effortlessly along an aluminium head track, when closed they form a secure fixed wall.



Movable wall system is a high quality bespoke movable wall system to suit timber panels up to 150 kiliograms in weight, there are multiple options for Door types, parking areas and track layouts.



Each door is a top hung straight sliding panel which sits inline with the other doors these panels can be moved into a parking area when the wall needs to be opened, pivot panels can be fixed or converted into sliding doors. Timber movable walls can be created to suit any space within reason.



Commercial Temporary Office Acoustic Room Dividers Melamine Surface 4m Height



Structure:



Acoustic room divider is the evolution of operable partition with blind panels and is a perfect acoustic room divider.


It is the answer to all the requirements of a physical, not visual, partition of the spaces and is a perfect acoustic room divider.



Thanks to its silent sliding system, to its thin structure in anodized aluminium and to the simple sliding of the seals, allows a light and transparent closure.



The vertical profiles, studied for the safety control of the inside glazed panels and for the edging of the elements, are coupled with male/female system. The glass (or the covering material) is completely enclosed within the aluminium frame: it is applied to it, not mechanically bound, allowing therefore a wide range of finishings alternatives.



Each element has two sliding rubber blocks, linked to mobile seals with soft gaskets: through a precision on them , the locking mechanism start to work and allows the locking in positions of the elements.



Structure:



The panels are operated by means of an internal scissor-jack mechanism and move effortlessly along an aluminium head track, when closed they form a secure fixed wall.



Movable wall system is a high quality bespoke movable wall system to suit timber panels up to 150 kiliograms in weight, there are multiple options for Door types, parking areas and track layouts.



Each door is a top hung straight sliding panel which sits inline with the other doors these panels can be moved into a parking area when the wall needs to be opened, pivot panels can be fixed or converted into sliding doors. Timber movable walls can be created to suit any space within reason.
