Customized Acoustic Sliding Folding Partitions / Meeting Room Divider Wall
Product Details:
| Place of Origin: | Guangdong |
| Brand Name: | BANGE |
| Certification: | ISO9001 |
| Model Number: | 85 mm sliding partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | US Dollars 80 - 120 per square meters |
| Packaging Details: | Carton package, MDF batten on four section sides , foam board on both front face. |
| Delivery Time: | 15-20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Open Style: | Sliding | Product Name: | Sliding Partition Walls |
|---|---|---|---|
| Feature: | Sound Proofing | Size: | 85 Mm |
| Color: | Accept Customized | Application: | Office,hotel,conference Room |
| Panel Width: | 500 Mm--1230 Mm | Door Material: | Melamine Board |
| Surface: | Melamine,leather,fabric,plywood | Position: | Interior |
| Width: | 85 Mm(3 1/4 Inch) | ||
| High Light: | acoustic sliding partition,sound proof sliding partitions |
||
Product Description
Meeting Room Acoustic Operable Partition Wall Conference Room Sliding Partition Walls
The advantages of sliding partition walls
1> Hanging system is hidden upon drop ceiling, won’t see any tracks on the finish floor.
2>Easy to collect, all the panels can be collected in a certain cabinet by one person, when a large space need to be recovered.
3>The surface of the movable sliding partition walls can be customized, can match the decoration style of the whole space.
4> The sliding partition wall is widely used in exhibition center, hotel, shopping malls, school, multi-function hall, banquet hall, conference room, training room,etc.
The details of the sliding partition walls
Movable sliding partition walls are specified where functional space delineation is an integral element within the partition project.
Due to their flexibility and cost effectiveness they allow large rooms to be conveniently sub-divided to maximize space utilization.
Principle applications include office interiors, meeting rooms, sports and leisure facilities, schools, colleges, churches, conference and function suites, exhibition centers, banks and restaurants.
To create a better sound insulation movable partition door, we put high density fiberglass inside the partition frame, Sourcing from imported world famous fiberglass brand " Owens Corning" which is the best sound insulation cotton manufacturer.
| Model | TG-65 series | TG-85 series | TG-100 series | TG-high series |
| Suspension system | Aluminum hanging | Aluminum hanging | Aluminum hanging | Steel hanging |
| Basic thickness | 65mm | 85mm | 100mm | 100mm |
| Total thickness | 65/75/85/95mm | 80/90/100/110mm | 100/120/130mm | 100/120/130mm |
| Max height | Up to 3800mm | Up to 4500mm | Up to 6500mm | Up to 12000mm |
| Width | 600-1230mm | 600-1230mm | 800-1230mm | 800-1230mm |
| Floor/ceiling sealing strength | Telescopic aluminum tube with rubber strip | |||
| Side walls sealing strength | Double seal tape | |||
| Sound insulation level | 26dB-30dB | 28dB-34dB | 32-40dB | 32-40dB |
| Panel structure | Aluminum frame with wooden keel | Aluminum frame with steel keel | ||
| Panel density | 22-28kg/sqm. | 24-32kg/sqm. | 32-50kg/sqm. | / |
| Surface material | Melamine laminate/fabric/PU leather/wallpaper/veneer/customized | |||
The function of the sliding partition walls
In general, the function of the sliding partition wall is to separate the interior space of the building with one or more decorative materials to separate the indoor space into two or more relatively independent spaces.
However, compared with the ordinary partition wall, the movable sliding partition wall has more privacy than the wall, such as sound insulation performance and thermal insulation performance, while the ordinary fixed wall has no sound insulation performance and thermal insulation performance. It is precisely because of the special function of the movable partition wall that it has a large choice in the way of construction, data selection and installation, which makes the designer more visually and artistically. In terms of comprehensive thinking, it has achieved a very good decoration effect, and even has a unique effect.
The movable sliding partition wall is used to divide the interior space of the room and the building. It is required to achieve the effect of ventilation and lighting, and requires its own light weight and thin thickness. Easy to remove and have a certain rigidity and sound insulation.
The movable sliding partition project has developed rapidly in recent years and has been adopted in many areas. There are many kinds of movable partition works. It can replace the heavy fixed partition project and change the wet operation of our country for many years. The movable partition is easy to install, which greatly speeds up the construction and does not affect the overall effect.
The function of the screen and the movable sliding partition wall is basically the same. The basic difference between the screen and the partition wall is that the upper part of the screen is not in contact with the indoor roof. The more direct expression is that the screen is not the partition of the roof, ie As long as the lower half or more half of the partition. The movable partition wall is a partition that hangs the zenith, which is more flexible than the movable partition screen.
