Acoustic Operable Sound Proof Partitions For Conference Room , Banquet Hall
Product Details:
| Place of Origin: | Guangdong |
| Brand Name: | BANGE |
| Certification: | ISO9001 |
| Model Number: | 85 mm sound proof partitions |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | US Dollars 80 - 120 per square meters |
| Packaging Details: | Carton package, MDF batten on four section sides , foam board on both front face. |
| Delivery Time: | 15-20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Open Style: | Sliding | Product Name: | Sound Proof Partitions |
|---|---|---|---|
| Feature: | Sound Proofing | Size: | 85 Mm |
| Color: | Accept Customized | Application: | Office,hotel,conference Room |
| Panel Width: | 500 Mm--1230 Mm | Door Material: | Melamine Board |
| Surface: | Melamine,leather,fabric,plywood | Position: | Interior |
| Width: | 85 Mm(3 1/4 Inch) | ||
| High Light: | movable sound proof partitions,movable soundproof partition |
||
Product Description
Acoustic Operable Sound Proof Partitions For Conference Room,Banquet Hall and Office
The features of sound proof partitions
1- 65mm ,85mm, 100mm aluminum frame thickness panel ,Max height up to 15 meters.
2-Top supported without floor track or guide, only have track on the ceiling.
3- clear anodized extruded aluminum tracks and frames,customized powder coated color are available.
4- Sound insulation certificate :STC 32db to 52db, ASTM standard of acoustic tested in HongKong.
5- Available in wide range of finishes, melamine ,fabric/PU leather, HPL, printing etc.
6- Fast delivery and Rich experiences in oversea project installation guide & supervision.
The details of the sound proof partitions
The operable sound proof partitions consist of a series of concave/convex profile interlocking flat panels and the fast set retractable top and bottom seals ,its provide excellent acoustic insulation property of from STC-32 to 53 in laboratory setting.
Its high performance per dollar value and the easiest in-field operation makes it very suitable for Hotel, banquet hall, conference room ,ballroom, muti-function hall, restaurant,classroom,office,religion,dance studio ,shopping arcades and many other place where seek for space divide with good soundproof performance .
The BUNGE Partition Walls is aluminum-framed operable sound proof partition is the most versatile operable wall constructed today. Partitions are a series of flat panels, approximately range from 600mm(23") to 1200mm(47") wide. They have a wide array of features and options to meet most design and budget requirements. Models are acoustically rated, available in 65mm(2.6") ,80mm(3")or 100mm(4") thick models, and in single, pair hinged configurations.
The continuously hinged panels are pulled from their parked position to ‘close’ (or extend) the wall and pushed back to the parked position to ‘open’ (or fold)the sound proof partitions wall. Final flat alignment of wall panels is assisted pneumatically by a gas piston located in the top track. A lever or recess handle is fitted to the lead panel and this combined with a vertical rebated profile provides the system with its pass door. The door is available with or without a lock cylinder.
| Panel Suspension: | Top hunge system without the need for a floor track. |
| Panel Width: | Each panel 600mm-1200mm. |
| Track: | Aluminum OR Steel Track |
| Rollor on panel | Single or double roller |
| Panel Frames: | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
| Top&bottm seals: | Top and bottom pressure retractable seals ensure effortless moved and locked. |
| Module: | 700mm - 1200mm maximum. |
| Panel stacking: | Numerous panel stacking options for complete flexibility. |
| Panel face: | MDF,Plywood,woven fabric.Leather,Natural wood veneer, Melamine,Wood moldings, etc |
| Finishes: | Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard. |
About us
The BUNGE company has a strong technical installation team and marketing team. The factory has introduced advanced foreign production technology, based on the advanced American partition technology, absorbs the essence of German and Danish partition technology, and continuously optimizes, improves and innovates to ensure products. It has excellent sound-absorbing and sound-absorbing effects, fire-retardant and flame-retardant properties, and at the same time absorbs professional technical talents. Through continuous innovation of technology, the products have better sound insulation effect and more flexible moving space function. There are 8 types of Ruizhuang movable partitions: 65 type, 85 type, 100 type, 125 ultra ultra high type and 65 type frameless glass, 85 type framed glass screen, and 32 type folding screen, among which the ultra high type movable partition With superior technical level, it adopts super-strong rails, imported hanging wheels, special-made barges and automatic steering system, with a height of up to 18m and a sound insulation coefficient of 55db. It is suitable for large-scale high-grade conference halls, banquet halls, exhibition halls. Exhibition halls and other professional venues.
