Sound Proof Movable Aluminum Partition Wall / Banquet Room Dividers
Product Details:
| Place of Origin: | Guangdong |
| Brand Name: | BANGE |
| Certification: | ISO9001 |
| Model Number: | 85 mm movable partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | US Dollars 80 - 120 per square meters |
| Packaging Details: | Carton package, MDF batten on four section sides , foam board on both front face. |
| Delivery Time: | 15-20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Open Style: | Sliding | Product Name: | Movable Partition Walls |
|---|---|---|---|
| Feature: | Sound Proofing | Size: | 85 Mm |
| Color: | Accept Customized | Application: | Office,hotel,conference Room |
| Panel Width: | 500 Mm--1230 Mm | Door Material: | Melamine Board |
| Surface: | Melamine,leather,fabric,plywood | Position: | Interior |
| Width: | 85 Mm(3 1/4 Inch) | ||
| High Light: | movable partitions systems,acoustic movable walls |
||
Product Description
Banquet Hall Aluminum Sound Proof Acoustic Movable Partition Walls
The details of BUNGE movable partition walls
Bunge Movable Partition Products as follow:
1. Ordinary Type : 65, 85; 100;
2. High Sound Proof Type: 85, 100;
3. Heavy Duty Type : 100, 125SH;
4. Glass Type: 65 (Glass Clip); 65 & 85(Aluminium Frame).
We Offer:
◆ A full professional design service
◆ Survery and installation guide
◆ Using top quality materials and components
◆ A fully experienced work team
◆ Maintenance contracts to ensure your valuable asset remains in full work order.
The different types of movable partition walls
The movable partition can divide a large space into several small spaces according to the usual situation, and can also splicing several small spaces into one large space. The partitioning method is divided into the following types by the number of blocks of the movable partition wall, the ability to use the sliding teeth and the push-pull track, and how to use the sliding teeth and the push-pull track. At present, Tiange's active partitions are mainly divided into 65 types of movable partitions, 80 types of movable partitions, 100 types of movable partitions and super high-sized movable partitions. The places where different movable partitions are often used are different.It is mainly divided into the following three categories:
The assembled movable partition wall is a partition that can be joined by a partition that can be attached or removed. Unlike other methods, it has no ordinary sliding teeth and push-pull rails. In order to facilitate the time-division operation of loading and unloading, the center of the uppermost part and the lowermost center of the movable partition wall are separately provided with some centers that can be better fixed.
The sliding movable partition wall is capable of adding the independent partitions in the assembled partition to the sliding teeth and the push-pull track, and then stopping the push-pull movement along the push-pull track to complete the partition. If the space of a space is larger than the demand of the space, if some of the sliding partition walls are collected, it will take up too much space and affect the beauty of a space at the maximum level, so another registration method should be adopted. For example, there is a storage room.
The foldable movable partition is a kind of partitioning method which is composed of a plurality of partition plates, sliding teeth and push-pull rails. The plurality of partitions can also be opened or closed according to practical conditions, which is convenient and quick, and is very sensitive.
| Description of the whole system | |
| Item | movable partition systems |
| Partition Height | 2-17 meters |
| Sound Transmission Class(STC) | 32-55db |
| Description of accessories | |
| Roller | Imported dupont POM material roller,bearing capacity 225-1300kg |
| Track System | Clear anodized 6063-T6 aluminum double track |
| Surface finish option | MDF,plywood, melamine,HPL,fabric,PU,wood veer, mirror steel ect. |
| Junction | "T"junction, "L" juntion, cross/ "X" juntion |
The procedure of installing the movable partition walls
1. Please designate the responsible person before construction and leave contact information to facilitate communication between the two parties on construction logistics.
2. If the ground has been finished before the track construction, if the carpet, floor tiles, floor, etc. have been laid, you need to do ground protection to prevent the welding sparks from damaging the ground.
3. You need to provide the height of the shed after the decoration is completed. We will determine the height of the track installation according to this height.
4. Because we need to calculate the size of the hanging track, you need to provide the net size of the finished wall and the pillar. We will hang the track according to this size.
5. After the track suspension is completed, the reserved wall size given by you cannot be changed. Because we calculate the construction according to this size, if the size is changed, the door panel will not operate.
6. After the track suspension is completed, our construction personnel will fill in the dimensional confirmation letter to provide accurate data for the production of the wallboard. You need to specify the person in charge of the site to confirm.
7. The movable partition should be horizontally perpendicular to the ground directly below the track, and the error should not exceed 1cm.
8. If there are other constructions at the same time, please do not pierce the foreign objects such as nails and insert them on the installed rails. This will cause the door pulleys to not run in the track.
9. Each group of tracks will have a “raw mouth”, which will be removed before installing the door panel, and then installed after the door panel is installed. This "raw mouth" cannot be sealed.
10. In order to facilitate future maintenance and maintenance, please reserve the inspection port near the ceiling track to facilitate the maintenance personnel to enter the inspection port for product maintenance and maintenance.
11. If you need to improve the sound insulation effect of the product, after the track is hung, you can make sound insulation between the track and the original shed.
12. After the door panel is hung, it needs to be debugged. Active partition reminder Do not use the door panel before our personnel have debugged the door panel, otherwise forcible use will result in damage to the door panel.
