Operable Movable Folding Partition Wall For Hotel Melamine Surface
Product Details:
Place of Origin: | China,Guangzhou |
Brand Name: | BUNGE |
Certification: | ISO9001 |
Model Number: | Series 65 mm acoustic room divider |
Payment & Shipping Terms:
Minimum Order Quantity: | 10 square meters |
---|---|
Price: | 104 / 136 dollar per square meter |
Packaging Details: | Carton package, MDF batten on four section sides ,foam board on both front face. |
Delivery Time: | Shipped in 10 days after payment, based on the quantity. |
Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
Supply Ability: | 5000 square meters per month |
Detail Information |
|||
Metal Type: | Aluminium+melamine | Width: | 500-1200 Mm |
---|---|---|---|
Open Style: | Folding | Function: | Soundproof |
Thickness: | 65 Mm | Height: | 4 M |
Service: | OEM Service | Surface: | Melamine |
Application: | Banquet Hall, Hotel | ||
High Light: | conference room dividers,banquet hall room dividers |
Product Description
Operable Walls, Movable Folding Partition Wall,Acoustic Room Dividers
Description:
Movable Partition Walls, the flexible space configuration, with little effort rooms can be partitioned, made smaller or larger to suit individual requirements, from conference rooms, school classrooms to large exhibition halls.
Options include single or double inset pass doors, glazing panels, virtually unlimited track arrangements and surface finishes, with melamine probably being the most popular.
The best door for maximum acoustic performance, with variable options on sound reduction from 32dB (Rw) to 53 dB(Rw).
Also available with 30 and 60 minute fire resistance.
Manual or Semi automatic operation.
Feature:
Individually operated, top hung panels, purpose made to suit any opening size upto 15 metres high.
Retractable top and bottom seals, able to deal with floor level differences up to 22.5 mm.
Mechanically operated by worm screw drive providing 2Kn of pressure for optimal acoustic performance.
No floor track.
Curved layouts, corner panels, junction panels, glazing cutouts, matching recess doors to special order.
Suitable for internal use only with a wide variety of features and finishes.
Acoustic performance :
Our sliding partition walls are consistently rated with the highest acoustical performance in the industry in real life environments not just in the Lab.
Identify Sound Flanking paths to reduce sound transmission to and from the entire acoustical envelope,walls, ceiling, floors, air ducts, windows, etc.
Determine optimal sound absorbing material to help minimize the level of sound generated in your space.
Sound proofing maximization.
Provide stylish acoustical design solutions.
Sound testing provided by us or independent sound testing company.
Application:
The operable wall series is used wherever room space needs to be fully utilized. Hotels, conference centers, educational establishments, offices, training areas, etc. can all benefit from the flexibility of Dividers operable walls.
Technical information:
TYPE | BG65 | BG85 | BG100 |
Panel suspension | Top hung only | ||
Track system | Single or twin point | ||
Panel thickness | 65 mm | 85 mm | 100 mm |
Panel height | Up to 4000mm,heights greater than 3000mm refer to our technical dept. | Up to 6000mm, heights greater than 6000mm refer to our technical dept. Inset passing doors above 2400mm. Full height passing door up to 3000mm high document ‘M’ disabled doors optional. | |
Max height | 4000mm | 6000mm | 18000mm |
Panel width |
500 - 1200mm 1' 5/8" -- 4' |
500 - 1200mm 1' 5/8" -- 4' |
500 - 1200mm 1' 5/8" -- 4' |
Frame | Aluminum | Aluminum | Aluminum |
Surface material | 9mm | 9mm | 12mm |
Fire safety | Optional class I | Optional class I | Optional class I |
Vertical profiles | Aluminum, anodized with sealing profiles, painter optional | Aluminum, anodized with sealing profiles, painter optional | Aluminum, anodized with sealing profiles, painter optional |
Retractable seals | Aluminum, black with double rubber seals | Aluminum, black with double rubber seals | Aluminum, black with double rubber seals |
Operation of seals | Manual, with supplied operating handle | ||
Locking | Optional lock to passing doors | ||
Passing doors | Single open in one panel or double open in two panel | ||
Sound insulation | 32-38dB Rw | 36-45dB Rw | 42-55dB Rw |
Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx 30-48kg/sq M |
Advantage:
Movable acoustic wall allow flexible and efficient space utilization combined with excellent acoustic performance in areas such as offices, hotels, exhibition centres, studios and many other applications.
Panel surfaces from veneer to laminates, enabling us to work with your interior design needs.
Manufactured to meet the acoustic requirements for education installations to school, colleges and Universities are second nature.
Product designed for a quick and easy set up operation.
Each panel is hinged together which allows you to move all the panels in one swift effort. We incorporate an access pass door as standard to give you extra space flexibility.
With each project and opening being different this product is ideal when there is no structural support as this system can be floor supported.
This product has been designed with your economical budget in mind,it is the versatile, durable and cost effective solution.
The fabric panel finish is fully washable and contains antimicrobial to protect against mildew, mold, fungi and bacteria making it the ideal solution for medical centres and hospitals.
