Product Details:

Place of Origin: Guangdong
Brand Name: BANGE
Certification: ISO9001
Model Number: 85 mm sliding partition walls

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: US Dollars 80 - 120 per square meters
Packaging Details: Carton package, MDF batten on four section sides , foam board on both front face.
Delivery Time: 15-20 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50000 square meters per month
Get Best Price Contact Now

Detail Information

Open Style: Sliding Product Name: Sliding Partition Walls
Feature: Sound Proofing Size: 85 Mm
Color: Accept Customized Application: Office,hotel,conference Room
Panel Width: 500 Mm--1230 Mm Door Material: Melamine Board
Surface: Melamine,leather,fabric,plywood Position: Interior
Width: 85 Mm(3 1/4 Inch)
High Light:

acoustic sliding partition

,

sliding folding partition

Product Description

Banquet Hall Soundproof Operable Walls/Classroom Sliding Partition Walls

The details of sliding partition walls

The sliding partition walls category

1.Single-style - The screen adopts two-wheel suspension, and each screen can be operated independently. It has a high degree of flexibility, can be turned, can be stored in any position, and can be combined into multiple moving spaces.

2. Two-piece type - The screen adopts a single wheel central suspension, and every two screens are hinged together at the rail to push and pull, can be folded, but can not be turned, suitable for quick installation, usually hidden on the main track The end.
The type of sliding partition walls

1. Ordinary board - The simplest screen, only has the up and down support function.

2. Telescopic plate - The necessary head plate for each group of screens, with telescopic function and up and down bracing function, used to compress and seal the entire group of screens.

3. The door in the door - has a screen center to open the door function and up and down support function.

4.Plastic rubber sheet - The necessary tail plate for each group of screens, with up and down support function, flexible soft rubber on the side of the plate, used for soft contact with the wall.
The model of sliding partition walls

1. 65 mm - Screen thickness 70mm, only applicable to heights up to 4 meters.

2. 85 mm - screen thickness 85mm, can apply to 8 meters below the height.

3. 100 mm - screen thickness 100mm, can be applied to 10 meters below the height.
Classroom Sliding Wall Dividers / Banquet Hall Soundproof Operable Partition Walls 0
The details of installing the sliding partition walls

(1)Size of wall: all the folding partition wall panels should be installed in accordance with the manufacturers recommendations.
(2)Cutting: all necessary hardware and accessories for a complete job installation are to be furnished by the contractor.
(3)Install the acoustic panels: the installation of acoustic panels should be carried out in a sequence from the left to the right, from upside to downside, the panels are cut to fit on site, traditional woodworking tools are suitable for cutting the panels, if panels are cut using a fine tooth table saw the panels should be cut face up to avoid scratching and at a much slower speed to avoid any tearout or chipping.
(4)Fix on keel:
Wooden keel fixing using nails, staples or screws into prefixed timber battens on the walls via the tongue and groove joint.It also can fixing by: light steel keel.

Classroom Sliding Wall Dividers / Banquet Hall Soundproof Operable Partition Walls 1

Description of the whole system
Itemmovable partition systems
Partition Height2-17 meters
Sound Transmission Class(STC)32-55db
Description of accessories
RollerImported dupont POM material roller,bearing capacity 225-1300kg
Track System Clear anodized 6063-T6 aluminum double track
Surface finish optionMDF,plywood, melamine,HPL,fabric,PU,wood veer, mirror steel ect.
Junction"T"junction, "L" juntion, cross/ "X" juntion


The features of sliding partition walls

1. It can divide the space arbitrarily along the track, smoothly passing through various turning points, flexible use of space

2. Durable aluminum outer frame, together with fire-resistant, sound-proof material, make it more prominent fire, sound insulation performance

3. Full range of partition type, can be used for different requirements of the site

4. When the sliding partition wall is in motion, the ceiling suspension system is stressed, and the ground is not laid on the ground rails to promote lightness and noise.

5. When the sliding partition walls are combined in the vertical and horizontal directions, they have fully taken into account the blocked sound wave propagation path and the use of soft sealing materials to make the sound insulation performance more pronounced.

6. Hidden handle operating mechanism, smooth partition wall line type, simple and reliable mechanical seal device, so that its quality is fully improved.

7. According to the needs of the scene to add a single open or open the partition wall door, improve the space utilization efficiency, the small door with a self-locking mechanism, also makes the sound wave can not spread

8. The top and bottom of the partition wall is equipped with an operating clearance of 20 to 30 mm, which can be adapted to the slight slope of the building surface.

9. The sliding partition wall terminal has a 100 mm operating clearance, which can be adapted to slight errors in the combination of building wall and partition wall.

10. The thickness of the 3mm decorative surface has been reserved on the surface of the partition to make its later decoration process more convenient and seamless with the frame.
Classroom Sliding Wall Dividers / Banquet Hall Soundproof Operable Partition Walls 2
