Lightweight Aluminum Wooden Movable Wall Partitions / Sliding Room Dividers
Product Details:
| Place of Origin: | Guangdong |
| Brand Name: | BANGE |
| Certification: | ISO9001 |
| Model Number: | 85 mm movable wall partitions |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | US Dollars 80 - 120 per square meters |
| Packaging Details: | Carton package, MDF batten on four section sides , foam board on both front face. |
| Delivery Time: | 15-20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Open Style: | Sliding | Product Name: | Movable Wall Partitions |
|---|---|---|---|
| Feature: | Sound Proofing | Size: | 85 Mm |
| Color: | Accept Customized | Application: | Office,hotel,conference Room |
| Panel Width: | 500 Mm--1230 Mm | Door Material: | Melamine Board |
| Surface: | Melamine,leather,fabric,plywood | Position: | Interior |
| Width: | 85 Mm(3 1/4 Inch) | ||
| High Light: | movable partitions systems,acoustic movable walls |
||
Product Description
Lightweight Aluminum Folding Sliding Wooden Movable Wall Partitions Price
Movable wall partitions --- 65,85,100,125 mm
BUNGE movable wall partitions provide a wide range of aesthetic,operational,and performance options and are the perfect solution to meet demanding space flexibility requirements. With over 10 years of acoyustic room dividers expertise, BUNGE movable wall partition has been the exclusive installing distributor of BUNGE movable wall partitions. Our designers can assist you early in your design with layout, structural support and storage pocket requirements, finish options, reliable budgets, and the myriad of other details required to make each application a success. Highlights include:
- Acousti-Seal and Encore product lines
- Single, Paired, and continuously hinged panel configurations
- Highly customizable finishes including wood veneers, rigidized metals, plastic laminates and more
- Flexible storage configurations
- Top hung and floor supported systems
- Manual and motor-operated systems
- Track systems stocked for quick-turn tenant improvement projects
- Structural support systems available
- In-house factory-certified installers and service techs
The structure of movable wall partitions
The BUNGE movable wall partitions structure is composed of aluminum profiles, sheets of treated particleboard or MDF and insulation. The combined structure forms a panel that has a total thickness of 82 mm and depending on the insulation material ensures a soundproof resistance of 32-53dB (decibels).
When the acoustic room divider is supported at the ceiling it runs along an adjustable aluminum upper track that is equipped with bearings inside of carriages. This enables the walls height to be adjusted by ±18 mm. The carriages are installed on every second wall panel and are located at the center of the panel. Because the acoustic room dividers wall hangs from the ceiling, it is important for the installation of the wall that the wall is attached to something solid (i.e. concrete ceiling, steel structure, wood beam etc.).
In the case that the folding wall is supported by the ground, an aluminum track is installed on the floor where the carriages move the wall and at the top there is a guiding track. The height is also adjustable by ±18 mm.
How to choose the partition walls
First, there are 65-type, 80-type, 85-type, 100-type and ultra-high-type partitions. The general area is small, and the indoor height is less than 3 meters. It is recommended to use 65-type movable partitions, economical, and larger space, like exhibition halls, theaters , Hotel lobby, you can see the situation to choose the thickness and height of the activities of the partition. The designer of Grethes can come to design the material for you. You don't have to worry about it.
In addition, there are also movable wall partition panels. The selection and color of the panel must be the main color of the composite space. There are a variety of styles of decorative partitions, including fabrics, soft leather bags, melamine boards, and wallpaper murals. Each material has hundreds of colors and styles.
| Description of the whole system | |
| Item | movable partition systems |
| Partition Height | 2-17 meters |
| Sound Transmission Class(STC) | 32-55db |
| Description of accessories | |
| Roller | Imported dupont POM material roller,bearing capacity 225-1300kg |
| Track System | Clear anodized 6063-T6 aluminum double track |
| Surface finish option | MDF,plywood, melamine,HPL,fabric,PU,wood veer, mirror steel ect. |
| Junction | "T"junction, "L" juntion, cross/ "X" juntion |
