Wooden MDF Restaurant Foldable Movable Sliding Partition Walls Rolling System
Product Details:
| Place of Origin: | Guangdong |
| Brand Name: | BANGE |
| Certification: | ISO9001 |
| Model Number: | 85 mm sliding partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | US Dollars 80 - 120 per square meters |
| Packaging Details: | Carton package, MDF batten on four section sides , foam board on both front face. |
| Delivery Time: | 15-20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Open Style: | Sliding | Product Name: | Sliding Partition Walls |
|---|---|---|---|
| Feature: | Sound Proofing | Size: | 85 Mm |
| Color: | Accept Customized | Application: | Office,hotel,conference Room |
| Panel Width: | 500 Mm--1230 Mm | Door Material: | Melamine Board |
| Surface: | Melamine,leather,fabric,plywood | Position: | Interior |
| Width: | 85 Mm(3 1/4 Inch) | ||
| High Light: | acoustic sliding partition,sound proof sliding partitions |
||
Product Description
Rolling System Wooden MDF Restaurant Foldable Movable Sliding Partition Wall
With sliding partition walls you can control how your space is utilised:
1.Space management ~ Movable walls offer an effective space solution for many environments including offices, educational establishments, sporting facilities, dining and entertainment facilities, religious centres, or retail area.
2.Smart use of space – Movable walls offer a flexible solution for making the most of an interior space. Room sizes can be changed in a matter of moments to capitalise on the revenue potential of commercial space or simply create the most efficient use of floor space
3.Acoustics ~ the movable wall is the highest specification range of fully operable, individual-panel systems. Acoustic insulation of up to 58dB noise reduction is achieved with a combination of acoustic infill’s and operable top and bottom seals.
4.Operation ~ space without a trace ~ when the operable seals are retracted the panels will glide effortlessly and quietly along the unique aluminium overhead track system (no need for floor guide). Final closure of each panel is by a removable operating handle that extends the seal from the top and bottom of each panel forming an acoustic seal.
5.Adaptable configurations – The track and carrier system provides ease of operation and directional flexibility, allowing panel stacking in countless configurations.
6.Panel options ~ Individual panels can be constructed with either manual or semi automatic retractable top and bottom seal. Panels are also available curved or with inset pass doors and glazed cut outs
7.Finishes ~ our systems can be supplied in an almost endless choice, popular finishes include MFC, veneers and laminates but we can also offer dry wipe, wall coverings and fabrics.
Our service includes:
Planned Preventative Maintenance
Our planned preventative maintenance service ensures the longevity of movable sliding partition wall installations and reduces the likelihood that expensive repairs or a replacement wall is required. By scheduling the maintenance period to suit the wall usage, BUNGE usually identify and eliminate the cause of operational difficulties and excessive wear and tear. Our experience shows that there is usually a marked reduction in the sound reducing performance as damaged or poorly working peripheral seals compromise the acoustic integrity. This causes complaints from users and in the worst case, loss of revenue as a result of poor acoustic performance.
Correct Operation
A large amount of repairs are as a result of incorrect operation by users. Movable wall panels are deceptively heavy due to the ease of operation but are capable of serious crush injuries. Your work place risk assessments should have taken this into account and state that only trained and authorised personnel my operate the wall.
BUNGE will offer training on the safe operation of your system to your staff.
Repairs and Refurbishment
A complete replacement of a movable sliding partition wall is usually unviable due to the supply and installation costs as well as the loss of revenue from having the wall system out of action for a prolonged period of time. BUNGE employ some of the most experienced movable wall engineers in the UK who are able to diagnose and repair most makes of movable sliding partition walls and sliding folding partitions.Where there has been external damage to panel faces, or just to keep up with changing environments, we are able to replace panel faces or decorate with bright fresh colours. Additional finishes included pin boards, dry wipe white boards and wall papers.
Full Replacement
Movable sliding partition walls and sliding folding partition do have a life cycle and there is a point where maintenance and repair becomes either impossible or uneconomical.BUNGE boasts over 12 years combined movable wall experience in the design, supply and installation of movable walls and sliding folding partitions. Utilising this experience we will assist you in choosing the correct movable wall system and specification that matches your requirements.
New Installations
BUNGE offers a full in-house design, supply and installation service to suit most applications ranging from high acoustic movable partitions to vinyl concertinas.
Technical data of Type 65 movable partition
| Panel Suspension | Top hanging system without the need for a floor track. |
| Panel Width | Each panel 600mm-1200mm. |
| Track | Aluminum Or Steel Track |
| Roller on panel | Single or Double Roller |
| Panel Frames | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
| Top and bottom seals | Top and bottom pressure retractable seals ensure effortless moved and locked. |
| Module | 700mm - 1200mm maximum. |
| Panel stacking | Numerous panel stacking options for complete flexibility. |
| Panel Surface | MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc. |
| Finishes | Satin anodized or polyester powder coating to all exposed aluminium components available in a wide range of colour as standard. |
Sliding partition walls application:
It is mainly applicable to office buildings, office buildings, airports, school buildings, banks, convention centers, government agencies, securities, automobile showrooms, and libraries. Also applies to hotels, shopping malls, schools, multi-purpose halls, banquet halls, conference rooms, training rooms and other places.
