Lightweight Movable Walls and Sliding Folding Partition Walls for Art Gallery

China Lightweight Movable Walls and Sliding Folding Partition Walls for Art Gallery supplier
Lightweight Movable Walls and Sliding Folding Partition Walls for Art Gallery supplier Lightweight Movable Walls and Sliding Folding Partition Walls for Art Gallery supplier Lightweight Movable Walls and Sliding Folding Partition Walls for Art Gallery supplier Lightweight Movable Walls and Sliding Folding Partition Walls for Art Gallery supplier

Large Image :  Lightweight Movable Walls and Sliding Folding Partition Walls for Art Gallery

Product Details:

Place of Origin: Guangdong
Brand Name: BANGE
Certification: ISO9001
Model Number: 85 mm folding partition walls

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: US Dollars 80 - 120 per square meters
Packaging Details: Carton package, MDF batten on four section sides , foam board on both front face.
Delivery Time: 15-20 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50000 square meters per month
Contact Now
Detailed Product Description
Open Style: Sliding Product Name: Folding Partition Walls
Feature: Sound Proofing Size: 85 Mm
Color: Accept Customized Application: Office,hotel,conference Room
Panel Width: 500 Mm--1230 Mm Door Material: Melamine Board
Surface: Melamine,leather,fabric,plywood Position: Interior
Width: 85 Mm(3 1/4 Inch)

Lightweight Movable Walls and Sliding Folding Partition Walls for Art Gallery



Specification:



The folding partition walls series is the highest specification range of fully operable, individual-panel movable partitions system. Acoustic insulation of up to 56dB noise reduction is achieved with a combination of operable top and bottom seals, high performance multiple in fill's and a panel assembly design that allows an acoustic break between the frame and outer layer.



The vertical channels of each panel incorporate polymer inserts that facilitate an acoustic seal when the panels are set out as a wall. Panels are produced in three thickness, 65 mm, 85 mm and 100 mm, depending on acoustic rating (from 37dB–56dB).



Our movable and folding partition walls system accessories are custom for each client and project,and they are also made of superior material.Track system for right-angled configurations with cross- roller carriers for element weights up to 500 kg. Support rollers in the junctions guarantee easy operation when sliding the elements across intersections .

Lightweight Movable Walls and Sliding Folding Partition Walls for Art Gallery



Folding partition walls feature:



Individual panels that can be stored away for maximum space utilization.



Operable top and bottom seals for effortless operation.



Isolated aluminium frame construction for enhanced acoustics.



High performance multiple in fill's for maximum sound attenuation.



Unique track and carrier system ensuring quiet and easy operation.



Numerous panel stacking options for complete flexibility.



No floor track ensuring obstruction free threshold.



Three panel sizes to accommodate a wide range of acoustic requirements .



Extensive range of surface finishes can be applied.


Lightweight Movable Walls and Sliding Folding Partition Walls for Art Gallery

Technical data of Type 65 movable partition :

Panel Suspension Top hanging system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum Or Steel Track
Roller on panel Single or Double Roller
Panel Frames Heavy-duty steel-gusseted aluminum inner frames reinforced with full height.
Top and bottom seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel Surface MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodized or polyester powder coating to all exposed aluminium components available in a wide range of colour as standard.

Folding partition walls description
The folding partition walls system offers excellent convenience. The individual movable folding partition walls elements are manually moved  to the required position. As soon as the contacts on the narrow end face of the elements close, the folding partition walls automatically extends the sealing strips within 5 seconds, with precisely the required contact pressure and with outstanding stability ensured every time. In the event of a power failure, the sealing strips can, of course, be manually operated.
The benefi ts at a glance:
- Electronically controlled extension and retraction of the sealing strips .
- Tight seal within just 5 seconds .
- Excellent stability .
- Uncomplicated plug&play installation

Lightweight Movable Walls and Sliding Folding Partition Walls for Art Gallery
