|Material:||Melamine||Product Name:||Folding Partition Wall|
|Height:||4 M||Width:||500-1200 Mm|
|Structure:||Aluminum Track,Trolley Bearing,Acoustic Door Panel||Certificate:||ISO9001|
|Application:||Conference Room,office||Thickness:||65 Mm|
|Sliding Door Type:||Partition Doors|
The flexibility of folding wall partitions can be divided or combined according to the different needs of different occasions. The use of an active partition can create a good decorative effect in the integration of the overall style of the room, and it also acts as a partition of the partition itself. The color of the partition is rich and colorful, and the colors are appropriately matched according to the owner's preference or the style of the room, and the permeability is enough to ensure privacy. At the same time, it is also possible to use some partitions with sound insulation as required.
With the continuous development of the industry, different styles and styles have appeared in the partitions. The appearance of hollow partitions has attracted more people's attention, and the hollow partitions can be used in various styles of places, whether Chinese or Western style, modern fashion style or ancient times. Elegant style has become a popular material. The partitions can be divided into different styles according to different standards. There are fixed and flexible points. There are also hard and soft differences. No matter what kind of partition has its own suitable place, it is usually used in the family and can separate the living room. Different space with restaurant, bedroom, balcony, etc.
In many European-style buildings, pillars are often used as a partition to make reasonable use of space and make the entire interior look elegant and atmospheric. In fact, many times apart from the separation space, the partition is used as a decorative item for people. For the selection of the partition, it is selected from specific requirements such as privacy, light transmission effect, sound insulation effect, or visual enjoyment. Flexible use according to different places, let the partition play the greatest value.
|Panel suspension||Top hung only||Top hung only||Top hung only|
|Panel thickness||65 mm||85 mm||100 mm|
|Max height||4000 mm||6000 mm||18000 mm|
|Panel width||500-1200 mm||500-1200 mm||500-1200 mm|
|Face material||9 mm||9 mm||12 mm|
|Pass doors||Single door or Double door|
|Sound insulation||20-32dB Rw||28-36dB Rw||32-50dB Rw|
|Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)|
Folding Partition Wall Feature:
1. The profiles of folding partition wall must be hard enough and have good horizon and practicality so that moving doors can seamlessly play a good sealing role and achieve real sound insulation.
2. In the sound insulation material, the color double layer production method and the high density density soundproof cotton are used to prevent heavy bass.
3. The sealing of the hotel activity screen should be specially processed. The inside should be made of natural sound insulation material instead of sponge.
4. It is best to choose sound-absorbing curtains and cloth table stools and carpets around the screens of hotel activities.
5. All soundproof walls adopt a very flexible vertical contact surface, with a groove-like tight fit principle to ensure optimal closing and sound insulation.
6. Hotel activities screen sliding door finishes use sound-absorbing panels or sound-absorbing flame-retardant fabrics instead of ordinary density boards.
Track: The tracks are made from extruded 6063 - T5 anodized aluminium. The track housing shall utilize grooves and interlocking steel pins for positive alignment of adjacent track sections, and shall be reinforced overhead by drop rod brackets. Aluminum track housing shall include an integral nut slot to accept a hardened square nut for attaching each drop rod bracket to the top of the track.
Panels:The Panels will be made from 12mm MDF boards and shall be 100mm thick and 1230mm maximum width, made to the appropriate acoustic rating and structural backing and mounted in full perimeter extruded aluminium frames with interlocking corner construction .The panel faces shall be finished with selected material.
Panel Surface Finish:The panel surface will be as per the clients requirement finished either in Sliwal factory – China or by others . The normal finish such as:laminate,veneer,melamine,fabric etc.
Seals: vinyl seal of butane rubber will be used as top and bottom and as well as closure seals for the operable wall system.Retractable seal drop will be 23mm.
