Sound Proof Office Sliding Acoustic Room Divider Wall with Aluminium Frame

China Sound Proof Office Sliding Acoustic Room Divider Wall with Aluminium Frame supplier
Sound Proof Office Sliding Acoustic Room Divider Wall with Aluminium Frame supplier Sound Proof Office Sliding Acoustic Room Divider Wall with Aluminium Frame supplier Sound Proof Office Sliding Acoustic Room Divider Wall with Aluminium Frame supplier Sound Proof Office Sliding Acoustic Room Divider Wall with Aluminium Frame supplier

Large Image :  Sound Proof Office Sliding Acoustic Room Divider Wall with Aluminium Frame

Product Details:

Place of Origin: China,Guangzhou
Brand Name: BUNGE
Certification: ISO9001
Model Number: Series 65 mm folding partition walls

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: 109 /141 dollar per square meter
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face.
Delivery Time: Shipped in 10 days after payment, based on the quantity.
Payment Terms: D/A, D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability: 5000 square meters per month
Contact Now
Detailed Product Description
Metal Type: Aluminium Panel Type: Melamine
Height: 4 M Color: Multi Color
Width: 500-1200 Mm Function: Soundproof
Service: OEM Service Door Material: Melamine Board
Open Style: Folding Thickness: 65 Mm
Application: Office, Conference Room Position: Commercial

Sliding Room Divider Sound Proof Office Folding Partition Walls



Specification:


Moveable walls are the standard product to use when dividing classrooms, training rooms, ball rooms, and gymnasiums. BUNGE offers several models including steel framed panel, steel reinforced frames, hinged pair panels, individual panels, curve & diver and electric wall type systems. BUNGE 's operable partitions are tested to high quality standards with life cycle, stress, and serviceability of the panels for our distributors and customers.



Feature:



(1) The surface can be made of any decorative surface, perfectly combined with the interior decoration style;



(2) The partitions are free to move freely and promote flexibility, which can be hidden in special storage cabinets without affecting the overall appearance;



(3) It can be used in conference rooms, exhibition halls, restaurants, training rooms, muti-function halls and other commercial establishments;



(4) Each screen is equipped with a telescopic mechanism, which can serve as a fixed screen and achieve soundproofing;



(5) According to different seating rates, large space can be divided into small spaces to reduce air conditioning power consumption;



(6)It is made of high-efficiency flame-retardant material and has good fireproof performance.


Sound Proof Office Sliding Acoustic Room Divider Wall with Aluminium Frame



Sound insulation:


The sound insulation coefficient of partitions comes from many directions, not only in the partition wall itself, but also in other links, as follows:


1. Horizontal sound insulation


In order to achieve the best sound insulation, two layers of sound-absorbing rubber structure are used. Using the jack principle, the double rubber strip is pressed against the ceiling track and floor to provide a high stability of the active partition.


2. Corner sound insulation


The use of specially shaped rubber-like corner elements solves the technical problems of handling corner seals; at the same time, superior stability and sound insulation are achieved.


3. Vertical sound insulation


All the soundproof walls are made of highly elastic vertical contact side, concave and convex groove close fitting principle, to ensure the best closure and sound insulation.


4. Skeleton


In view of the hanging structure of the wall plate, it can be freely shaken, and the metal hoop elements between the wall plates are closely combined, effectively blocking the sound transmission. Panels can be replaced as needed for interior design without damaging the entire panel.


5. Sound insulation material


The skeleton is filled with additional sound insulation materials to achieve different sound insulation requirements.


6. Operating crank


Manually operated crank controls the expansion and contraction of the soundproof strip. The flexibility of the in-crank diamond connection bayonet makes it difficult to slide the crank.


7. Panel


The wallboard skeleton consists of aluminum alloy and steel pipe. This sturdy, skeleton, coupled with the tight integration of the wall sheet metal hoop elements, provides great stability and high sound insulation.


Technical information:



Panel Suspension Top hanging system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum Or Steel Track
Roller on panel Single or Double Roller
Panel Frames Heavy-duty steel-gusseted aluminum inner frames reinforced with full height.
Top and bottom seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel Surface MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodized or polyester powder coating to all exposed aluminium components available in a wide range of colour as standard.


Sound Proof Office Sliding Acoustic Room Divider Wall with Aluminium Frame

Movable Partition Wall Instruction:


First, how to open a muti-directional screen. All operations should be gentle and should pay attention to safety. Facing the screen station, use both hands to grab the screen and pull the screen in the direction of the rails; turn the screen in the direction of the rails. After pushing the screen to its place, fix the screen. Tip: When pushing the screen to the intersection, you should pay attention to the direction of the rail, and then gently push the screen along the rail to the position where it should be placed.



Second, how to fix a muti-directional screen. With one hand holding the screen, the other hand puts the handle into the hexagonal steel at 1100mm on the side of the screen, grasps the handle and rotates it 180 degrees in the clockwise direction, and the telescopic seal inside the screen pops up to fix the screen. Insert the handle into the groove on the side of the screen, and pull the handle upwards to open the expansion screen inside the screen to fix the screen. After the entire group of screens are placed, check whether the screen is straight, whether it is on the same plane as the rails, and if it is not straight, retract the upper and lower expansion seals until the screen is flat.



Surface:



1. The partition wall of the movable partition series consists of glass, melamine board, fire board, color steel plate, gypsum board and other decorative materials.


2.The heart is made of aluminum alloy frame and steel with fire, moisture, noise, environmental protection, non-deformation and other functions, in the hotel partition layout, color and surface decoration, etc. to maintain the hotel after the partition is simple and exquisite, durable and flexible use Diversified spaces and very stylish hotel interior style after partition.
