Sliding Home Fabric Office Accordion Partition Walls Movable Demountable
Product Details:
| Place of Origin: | Guangdong |
| Brand Name: | BANGE |
| Certification: | ISO9001 |
| Model Number: | 85 mm sliding partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | US Dollars 80 - 120 per square meters |
| Packaging Details: | Carton package, MDF batten on four section sides , foam board on both front face. |
| Delivery Time: | 15-20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Surface: | Melamine,leather,fabric,plywood | Position: | Interior |
|---|---|---|---|
| Open Style: | Sliding | Product Name: | Sliding Partition Walls |
| Feature: | Sound Proofing | Size: | 100 Mm |
| Color: | Accept Customized | Application: | Office,hotel,conference Room |
| Panel Width: | 500 Mm--1230 Mm | Door Material: | Melamine Board |
| High Light: | sliding folding partition,sound proof sliding partitions |
||
Product Description
Sliding Home Fabric Office Accordion Partition Walls Movable Demountable
Sliding Partition Walls Features:
1. Make the construction period shorter, the construction pollution is less, convenient and quick, and it has a strong decorative and versatile use.
2. The sliding partition walls connects the two different thick and thin compartment systems on the single side and the double side through connectors, and the angle of the design can be changed to make the space design wider and wider.
3. The combination of strong elasticity, can be reused to reduce the replacement cost, office screen partition plays a role in environmental protection, energy saving, and has a strong decorative and versatile use.
4. The changeable material design of the office screen makes the overall indoor environment design and style closer to the corporate culture.
5. With the line function can be done at any time line maintenance, safety, convenience and does not affect the overall appearance.
6. The outer frame is aluminum products, the surface material is non-combustible or non-flammable materials, office screen partition with fire protection and its sound insulation properties.
Operation.
The continuously hinged panels are pulled from their parked position to ‘close’ (or extend) the wall and pushed back to the parked position to ‘open’ (or fold)the wall. Final flat alignment of wall panels is assisted pneumatically by a gas piston located in the top track. A lever or recess handle is fitted to the lead panel and this combined with a vertical rebated profile provides the system with its pass door. The door is available with or without a lock cylinder.
Standard Type
Sliding partition walls system are 2-1/4” tongue-and-groove unitized panel system. Panels are 24” wide, precision laminated, and pre-finished with vinyl, fabric or other specified finish. Panels are manufactured at various heights up to 59’. All vertical and horizontal structural members consist of extruded aluminum components, with a snap-on base made of extruded vinyl. Panels lift into floor and ceiling tracks to form a rigid, uniform wall system that provides excellent sound transmission resistance with a STC rating of 35 to 58dB.
Who we are?
The BUNGE Sliding Partition Walls is aluminum-framed operable partition is the most versatile operable wall constructed today. Partitions are a series of flat panels, approximately range from 600mm(23") to 1200mm(47") wide. They have a wide array of features and options to meet most design and budget requirements. Models are acoustically rated, available in 65mm(2.6") ,80mm(3")or 100mm(4") thick models, and in single, pair hinged configurations.
|
Panel Suspension
|
Top hunge system without the need for a floor track.
|
||
|
Panel Width
|
Each panel 600mm-1200mm.
|
||
|
Track
|
Aluminum OR Steel Track
|
||
|
Roller on panel
|
Single or Double Roller
|
||
|
Panel Frames
|
Heavy-duty steel-gusseted aluminum inner frames reinforced with full height.
|
||
|
Top&bottm seals
|
Top and bottom pressure retractable seals ensure effortless moved and locked.
|
||
|
Module
|
700mm - 1200mm maximum.
|
||
|
Panel stacking
|
Numerous panel stacking options for complete flexibility.
|
||
|
Panel face
|
MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
|
||
|
Finishes
|
Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard.
|
||
The kind of sliding partition walls
1.Stainless steel glass partition
Standard brushed stainless steel decorative frame with built-in metal keel, 10-12MM tempered safety glass, professional Tig welding and firmware fixed glass joint edge seam and around the glass plastic edge processing, in order to achieve earthquake safety requirements of the assembly quickly, concise and applicable The large office and office space environment demonstrates the simplicity and rationality of a modern office.
2. Plasterboard partition
The high partition of the office adopts the light steel keel as the basic skeleton, and the built-in soundproof rock wool is fixed with gypsum board on both sides with self-tapping screws, and the nail surface is brushed with anti-rust paint fiber-joint gypsum to caulking, affixed with kraft paper, putty leveling, sand silk grinding, brushing Finishes, smooth effect.
3. Aluminum-magnesium alloy partition
Aluminium-magnesium alloy profile assembly frame is built with 10-12MM single-layer toughened safety glass or other special craft glass, PVC environment-friendly special rubber strip closes, the frame is fixed with special firmware, and the structure is very stable. The whole construction is an assembly process without any environmental pollution And can be reused, office high partition of its optical and thermal performance, thermal conductivity and other indicators are in line with national standards.
4. Double glass high compartment
Aluminum-magnesium alloy or other special profile frame tempered double glass built-in manual or electric louver, profile frame and louver color can be freely selected, suitable for high-end office space Zhang Xian office space elegance and chic.
5. Movable partition
The movable partition metal track is installed in a reasonable position and is fixed on the high-efficiency fire-proof partition board. It is easy to push and release, and the whole can decorate the surface according to the indoor effect, and the appearance and sound insulation are excellent.
