Soundproofing Sliding Partition Walls Suspended Ceiling Hanging System
Product Details:
| Place of Origin: | Guangdong |
| Brand Name: | BANGE |
| Certification: | ISO9001 |
| Model Number: | 85 mm sliding partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | US Dollars 80 - 120 per square meters |
| Packaging Details: | Carton package, MDF batten on four section sides , foam board on both front face. |
| Delivery Time: | 15-20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Panel Width: | 500 Mm--1230 Mm | Door Material: | Melamine Board |
|---|---|---|---|
| Surface: | Melamine,leather,fabric,plywood | Position: | Interior |
| Open Style: | Sliding | Product Name: | Sliding Partition Walls |
| Feature: | Sound Proofing | Size: | 85 Mm(3 1/4 Inch) |
| Color: | Accept Customized | Application: | Office,hotel,conference Room |
| High Light: | sliding folding partition,sound proof sliding partitions |
||
Product Description
Suspended Ceiling Hanging System Soundproofing Movable Sliding Partition Walls
How to install the sliding partition walls
1. After the movable sliding partition rail is transported to the construction site, the construction personnel should first understand the general decoration style of the site, including the shape of the ceiling, the ground modeling, whether there is a foot line on the wall, etc., communicate with the on-site carpenters in time, and then put the line to determine the track installation. position;
2. After the horizontal line is laid down, determine the layout of the air-conditioning duct and fire control pipe, etc. with the construction party to facilitate the determination of the steel structure installation form. It is a straight pull or diagonal support or U-slot fixed, these are responsible installation teams should Do the pre-construction preparations, or else work hastily, affect the on-site construction layout at the time, but also to work again and again, seriously affecting the progress of the construction, but also bring unnecessary trouble to Party A;
3. After the rails are installed, inspect the track horizontally again, and finally perform rust-proof treatment on the steel structure. Then notify Party A to accept and explain clearly the position of the track's movable mouth. When clearing the ceiling of the ceiling, the track cannot be fixed with this section, otherwise loading and unloading. The door panel will likely destroy the integrity of the ceiling.
What is the door in doors
With the renovation of hotels, restaurants, tea houses, and modern and simple office meeting rooms, the practicality of the event partition has gradually become popular and widely used. In the daily partitions, it is inevitable that you will need to use the door in the door, so that there is a passage in the separated space. We will now introduce the door in the middle of the partition.
The so-called door in the door, is to open a set of small doors in the partition door to facilitate access. There are two kinds of conventional door doors, one is a single door, and the other is a double door.
Single pass door is generally 700-800mm wide and 2100mm high; double door is 1600mm wide and 2100mm high.The door door trim can be unified according to the ordinary door panel decoration, but in some cases, the door door needs to do a separate style.
|
Panel Suspension
|
Top hunge system without the need for a floor track.
|
||
|
Panel Width
|
Each panel 600mm-1200mm.
|
||
|
Track
|
Aluminum OR Steel Track
|
||
|
Roller on panel
|
Single or Double Roller
|
||
|
Panel Frames
|
Heavy-duty steel-gusseted aluminum inner frames reinforced with full height.
|
||
|
Top&bottm seals
|
Top and bottom pressure retractable seals ensure effortless moved and locked.
|
||
|
Module
|
700mm - 1200mm maximum.
|
||
|
Panel stacking
|
Numerous panel stacking options for complete flexibility.
|
||
|
Panel surface
|
MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine.
|
||
|
Finishes
|
Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard.
|
||
About the sliding partition walls
Sliding partition walls are also called active partitions, movable partitions, movable boards, movable screens, mobile partitions, mobile screens, mobile soundproof walls, and are derived from German technology. The movable sliding partition wall has the characteristics of easy installation, reusability, industrial production, fire prevention, and environmental protection.
Sliding partition wall is a kind of movable wall that divides a large space into a small space or a small space into a large space at any time according to needs and has a general wall function. An independent space area can function as a multi-purpose room and a multi-room use.
The sliding partition wall is also called the active partition, which can be called the active partition, the mobile partition wall, the rail partition, and the mobile sound insulation wall. The movable partition has the characteristics of easy installation, reusability, industrial production, fire prevention, and environmental protection.
The movable sliding partition wall brings great convenience to people's work. For example, when you need it, you can fold it on one side to make the two spaces fit together and appear larger. This facilitates temporary departmental meetings. As another example, the activities are highly partitioned. In general, our company's factory may be rented. For various reasons, we have to change places. The disadvantage of traditional partitions at this time is easily revealed because you cannot take away the components that belong to the house. On the contrary, the activity partition is removable, can be taken away, and can be reorganized, so the activity partition has the reputation of being able to take away the decoration.
The sliding partition wall has the characteristics of high sound insulation, fire prevention, mobility, and easy operation. It is extremely suitable for the use of space separation in star hotel ballrooms, high-grade restaurant rooms, and high-grade office meeting rooms. At present, the activity partition and fixed partition series products have been widely used in hotels, guesthouses, restaurants, clubs, multi-function halls, conference rooms, banquet halls, office buildings, exhibition halls, financial institutions, government office buildings, hospitals, factories and other occasions.
In recent years, sliding partition walls products have been widely adopted by modern designers, and they have been perfectly integrated with foreign technologies. They have become more mature in the market and have won deep recognition from the hotel industry, restaurant industry, government enterprises and other industries.
