Acoustic Wooden Sliding Partition Walls For Function Room / Exhibition Hall
Product Details:
| Place of Origin: | Guangdong |
| Brand Name: | BANGE |
| Certification: | ISO9001 |
| Model Number: | 85 mm sliding partition walls |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 square meters |
|---|---|
| Price: | US Dollars 80 - 120 per square meters |
| Packaging Details: | Carton package, MDF batten on four section sides , foam board on both front face. |
| Delivery Time: | 15-20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 square meters per month |
|
Detail Information |
|||
| Panel Width: | 500 Mm--1230 Mm | Door Material: | Melamine Board |
|---|---|---|---|
| Surface: | Melamine,leather,fabric,plywood | Position: | Interior |
| Open Style: | Sliding | Product Name: | Sliding Partition Walls |
| Feature: | Sound Proofing | Size: | 85 Mm(3 1/4 Inch) |
| Color: | Accept Customized | Application: | Office,hotel,conference Room |
| High Light: | acoustic sliding partition,sliding folding partition |
||
Product Description
Function Room Acoustic Movable Wooden Soundproof Sliding Room Partition Walls
Sliding partition walls details
Product Model: 65 Type 85 Type 100 Type 120 Type
Operation mode: Manual semi-automatic automatic
Product Category: Sliding partition walls
Finishing category: MDF (MDF) Non-painted board Cloth or leather bag Soft bag Finishing
Rails: Aluminium rails Rails.Hanging wheel POM particle wear-resistant pulley
Features:
Insulation and energy-saving: excellent heat insulation performance, according to different occupancy rates, the large space is divided into small spaces to reduce air-conditioning power consumption
Suspension: There is no track on the ground. The edge of the lower edge of the track is slightly lower than the ceiling. The ceiling can be closed.
Flexible operation: The partitions move freely, promote flexibility, and one person can complete the entire process of partitioning.
Collection is convenient: When closing, the partition can be hidden in a dedicated storage cabinet, does not affect the overall appearance.
Fire protection: It is made of high-efficiency fireproof materials and has good fireproof performance;
Sound insulation: Good sound insulation effect, maximum sound insulation coefficient up to 53dB;
Safety: When the top and bottom battens are extended, the top brace is not easy to swing;
Applications: Office conference room, exhibition hall, restaurant box, hotel banquet hall
Hanging wheel: The roller material is imported POM polyformaldehyde, the screw material is No. 45 quenched and tempered steel, and the hanging screen can be rotated at any angle in the horizontal plane, and can pass along the L, T, X intersection of the track along the pulley.
Telescopic mechanism: Material is standard 45 steel and spring steel, pressure spring type operation, can automatically adjust the gap between the screen and the ground.
Sound insulation cotton: PAR sound-absorbing glass fiber, fire performance, thermal resistance and noise reduction coefficient are in line with the United States ASTM standards.
Upper and lower plunging strips: Anodized aluminum, sealed screen and floor, gap between ceilings, and soundproofing for fixing.
Sealant strip: PVC polyvinyl chloride material, the surface color is black, seal sound, seal light, contact wall buffer effect.
Frame: Material is anodized aluminum, vertical embedded lock, can seal leaks from narrow gaps in the screen frame.
Cover: The material is a standard 45 steel, black chrome plating, built-in spring, protection rod device.
Stirring bar: Made of standard 45 gauge steel, it is used to operate up and down, left and right telescopic mechanisms.
Track: The material is made of 6063-T6 anodized aluminum, used for hanging screens.
Wheel base: Made of A3 steel, it connects the effect of double-level hanging wheels and screens.
Substrate: Medium density fiberboard, all in compliance with GB/T11718-1999.
The ultra-high sliding partition walls, as the name suggests, is a general large-scale banquet hall or conference center and other places where the height of the ceiling is relatively high, usually 8 meters or more, or even 12 meters, and even worse, a place with a height of 15 meters. Multi-purpose hall, and the selected activities are cut off.
In such a high place, the door panels are relatively heavy. In other words, the selected partitions are completely suspended on the steel structure. The weight of the tonnage or even more than ten tons is above the ceiling structure. The installation requirements for the steel structure are very high.
The general structure is relatively complex, the conventional concrete reinforcement structure, tennis steel structure, or simple steel structure, etc., for different housing structures, professional partition manufacturers need to carry out surveys on the site, and then make a professional steel structure installation program. The partition has 15 years of experience in the installation of steel structures. The installation team is also equipped with relevant steel installation qualification certificates. Some employees have also participated in the design and installation of large-scale bridges. They have performed well in the installation of steel structures. Each project is given The optimal and safest design strategy ensures the safety, stability and sealing performance of the sliding partition walls.
|
Panel Suspension
|
Top hunge system without the need for a floor track.
|
||
|
Panel Width
|
Each panel 600mm-1200mm.
|
||
|
Track
|
Aluminum OR Steel Track
|
||
|
Roller on panel
|
Single or Double Roller
|
||
|
Panel Frames
|
Heavy-duty steel-gusseted aluminum inner frames reinforced with full height.
|
||
|
Top&bottm seals
|
Top and bottom pressure retractable seals ensure effortless moved and locked.
|
||
|
Module
|
700mm - 1200mm maximum.
|
||
|
Panel stacking
|
Numerous panel stacking options for complete flexibility.
|
||
|
Panel surface
|
MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine.
|
||
|
Finishes
|
Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard.
|
||
About BUNGE sliding partition walls
1. The decorative partition of the sliding partition wall has the characteristics of anti-cut, cut, knock, and hit, and the panel data used is robust, fireproof and anti-wear.
2. The portrayal of the image, the sliding partition wall is convenient in the hotel, and can be a flexible room to form a box. The box can be taken away. Wherever there is a track, there are active boxes. The hotel is partitioned by activities to show the hotel's fashion.
3. The deployment of sliding partition walls color, when the decorative activities are cut off, the interval style can be planned according to the customer's decorative personality. In general, color harmony and cold. The darkness seems to look calm, calm, clear colors and elegant appearance, calm looks handsome, beautiful appearance, always return to the various colors between the intervals properly
4. The sliding partition walls of the combined space has strong ability to cut the space and composition space at any time and at any place. It is useful for the hotel box and constitutes a box. It only needs to move the interval. The movable office partition wall is very free, and the office partition plan should pay attention to the height, length, and size of the drawings.
