Acoustic Folding Office Partition Walls , Movable Decorative Room Divider Aluminium Track

Acoustic Folding Office Partition Walls , Movable Decorative Room Divider Aluminium Track

Product Details:

Place of Origin: Guangdong,China
Brand Name: BUNGE
Certification: ISO9001
Model Number: 65 mm office partition walls

Payment & Shipping Terms:

Minimum Order Quantity: 10 square meters
Price: 85 / 118 dollar per square meter
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face.
Delivery Time: Shipped in 10 days after payment, based on the quantity.
Payment Terms: D/A, D/P, T/T, L/C, Western Union, MoneyGram
Supply Ability: 5000 square meters per month
Get Best Price Contact Now

Detail Information

Thickness: 65 Mm Surface: Melamine,leather,fabric
Color: Multi Color Material: MDF Board+Aluminium
Application: Office,conference Room Height: 4 M
Width: 500-1200 Mm Service: OEM Service
High Light:

acoustic operable wall

,

movable acoustic partition walls

Product Description

Acoustic Folding Office Partition Walls , Movable Decorative Room Divider Aluminium Track

Acoustic Folding Soundproof Office Partition Walls

Specification:

The effective division of space some times requires utmost flexibility.Whether the requirement is to divider a teaching area,temporarily partition a conference suite,or simply create extra rooms out of one large space, the answer is movable walls sliding folding partitions. Bunge operable walls, the products also include,hinged partitions and concertina folding partitions along with a range of glass movable walls and industrial doors. Bunge provides unrivalled experience in the design and manufacture of space utilization products.

Feature:

(1)Individual panels that can be stored away for maximum space usage.
(2)Operable top and bottom seals for effortless operation.
(3)Aluminium frame construction for enhanced acoustics.
(4)The system offers various levels of sound reduction.
(5)Unique track and carrier system ensuring quiet and easy operation.
(6)Numerous panel stacking options for completer flexibility.
(7)Top hanging and no floor track.
(8)Expensive range of surface finishes can be available.


Acoustic Folding Office Partition Walls , Movable Decorative Room Divider Aluminium Track 0

Usage:

(1)Constructing location: keep dry, the temperature should be higher than 10'C, the widest humidity range should confined to 40%-60% after construction 24 hours before constructing, the location should reach the standards as above.


(2)Acoustic panels: for the acoustic panels accommodated to the circumstance of constructing, please place the panels in the constructing location for 48 hours, check up the type, specification and amount of the panels before constructing.


(3)Keels: fix the keels on the wall flatly according to the plan, the keels should be flat, slick, no rust, no metamorphosis; the wall must be construct according to the standards, the keels suitable install with acoustic panels, leave smaller than 500mm space between each wooden keel(smaller than 600mm of light steel keel), install the keels vertically with acoustic panels.

Acoustic Folding Office Partition Walls , Movable Decorative Room Divider Aluminium Track 1

Technical Information:



Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Panel thickness 65 mm 85 mm 100 mm
Max height 4000 mm 6000 mm 18000 mm
Panel width 500-1200 mm 500-1200 mm 500-1200 mm
Face material 9 mm 9 mm 12 mm
Pass doors Single door or Double door
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc.



Advantage:

Long-term use: with more economy and higher decorative, beautiful and safe, will not scratch the skin.
Cost savings: installation does not affect the construction of smallpox and the ground.
Various forms: optional with a variety of occasions partition wall, can be customized according to customer requirements.
Easy combination: in the re-assembly can make full use of building materials.
Material environmental protection: selection of high-quality melamine particleboard, sound insulation and sealing a good variety of accessories a variety of options.


Accessories details:



Panel Surface Finish:The panel surface will be as per the clients requirement finished either in Sliwal factory – China or by others . The normal finish such as:laminate,veneer,melamine,fabric etc.



Seals: vinyl seal of butane rubber will be used as top and bottom and as well as closure seals for the operable wall system.Retractable seal drop will be 23 mm.



Aluminium trim: The panel trims will be standard series with exposed Aluminium trims of 10mm thickness finished in 6063 - T5 Anodized Aluminium shall be used.


Acoustic Folding Office Partition Walls , Movable Decorative Room Divider Aluminium Track 2
