Product Details:

Place of Origin: Guangzhou, China
Brand Name: EBUNGE
Certification: ISO9001
Model Number: 85 mm acoustic partition walls installation

Payment & Shipping Terms:

Minimum Order Quantity: 100 square meters
Price: US 3.8 - 32.8 dollars per square meter
Packaging Details: Paper carton
Delivery Time: 15 - 20 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500000 square meters per month
Get Best Price Contact Now

Detail Information

Product Name: Acoustic Partition Walls Installation Weight: 38 - 45KG/sq M
Material: MDF + Aluminum Application: Banquet Hall, Hotel, Conference Hall
Color: Accept Customized Finishing: Laminate, Melamine, Leather Or Fabric
High Light:

acoustic operable partitions

,

acoustic operable wall

Product Description

Fireproof Movable Soundproof Partition Wall System Mobile Acoustic Partition Walls Installation Details

Fireproof Movable Soundproof Partition Wall System Mobile Acoustic Partition Walls Installation Details

Acoustic partition walls installation details



1)Interlocking male / female trapezoidal vertical aluminium profiles, for soundproof connection between elements.

2)To ensure additional friction connection, shall be integrated with magnetic strip.

3)Acoustic partition wlals installation are easy element adjustment after installation.

4)Track system shall be Extruded aluminium, maintenance free with heavy-duty ball bearing steel rollers.

5)Surface panel shall be of 9mm or 12mm MDF with acoustic treatment to the required level.


6)Acoustic partition walls installation is modernized decoration style. It can separate the space speedly and conveniently. And it has sound insulation and heat insulation and fireproof function;

7)The acoustic partition walls installation is made from high density s/s frame, special made rubber, excellent sound insulation cotton and finish board etc. the finish board is flat and hard;

8) The finish acoustic partition wall is inserted in the aluminum track, assembled with multi direction wheels;

The acoustic partition walls board can be stored in may different ways;

9) It doesn’t need track on the floor, we only hang the track on the ceilings and it can be at the same plane with the ceiling decoration. It won’t affect the whole decoration style;

10) Around the board ,there is sound insulation rubber, it can help to insulate the sound entering;

11) The operation ways is much easier, it’s better than the old ways which was use spring before;

12) We can add single or double doors on the board for convenience;

13) We have many different finish to meet customer different requirement and get different decoration effect.

Fireproof Movable Soundproof Partition Wall System Mobile Acoustic Partition Walls Installation Details 0


Acoustic partition walls installation features



1. Insertion loss of the order of 15 to 30 dba is achieved.​



2. Vibration isolation, noise-controlled, shock-resistant systems.



3. Indoor or outdoor applications.



4. Full installation service and modular solutions.



5. The delivery time is 3 weeks from the date of PO raised.



6. Attractive after sale service and AMC packages for the hassel free operation of the enclosures.

Fireproof Movable Soundproof Partition Wall System Mobile Acoustic Partition Walls Installation Details 1



Acoustic partition walls installation technical information


TYPE BG65 BG85 BG100 & BG125
Panel suspension Top hung only
Track system Single or twin point
Panel thickness 65 mm 85 mm 100 mm
Panel height Up to 4000mm,heights greater than 3000mm refer to our technical dept. Up to 6000mm, heights greater than 6000mm refer to our technical dept. Inset passing doors above 2400mm. Full height passing door up to 3000mm high document ‘M’ disabled doors optional.
Max height 4000mm 6000mm 18000mm
Panel width

500 - 1200mm

1' 5/8" -- 4'

500 - 1200mm

1' 5/8" -- 4'

500 - 1200mm

1' 5/8" -- 4'

Frame Aluminum Aluminum Aluminum
Surface material 9mm 9mm 12mm
Fire safety Optional class I Optional class I Optional class I
Vertical profiles Aluminum, anodized with sealing profiles, painter optional Aluminum, anodized with sealing profiles, painter optional Aluminum, anodized with sealing profiles, painter optional
Retractable seals Aluminum, black with double rubber seals Aluminum, black with double rubber seals Aluminum, black with double rubber seals
Operation of seals Manual, with supplied operating handle
Locking Optional lock to passing doors
Passing doors Single open in one panel or double open in two panel
Sound insulation 32-38dB Rw 36-45dB Rw 42-55dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx 30-48kg/sq M
Fireproof Movable Soundproof Partition Wall System Mobile Acoustic Partition Walls Installation Details 2
